2: System Overview

System Enclosure

20
The Silicon Graphics Prism Deskside visualization system is housed in the system
enclosure as shown in Figure 2-1 and Figure 2-2. The enclosure provides structure and
protection for the internal components.
Hard disc
drive housing
2
TM
Figure 2-1 System Enclosure Layout (Right-Front View with Side Panel Removed)
Disc drive backplane
I/O daughtercard
Disc drive
cooling fan
N !
T IO
C A U
N !
T IO
C A U
DIMMs
Airflow baffle
007-4772-002
