NTI SPLITMUX-DVI-4RT Installation And Operation Manual page 81

HOTMOUSE
HOTMOUSE CURSOR IN PIP MODE
Hotmouse Cursor in PIP MODE (continued)
Modify size of PiP images
Activate Hotmouse Cursor and move to the left edge of the PiP image area until horizontal arrows appear in the
Hotmouse Cursor. Hold down the left mouse button and drag the Hotmouse Cursor to the left to increase PiP
image size, or to the right to reduce PiP image size.
Note:
As soon as the Hotmouse Cursor moves to the left edge of the PiP image area, its appearance
changes (horizontal arrows, channel number).
Scaling PiP images up
2
Scaling PiP images down
2
76
SPLITMUX - Installation and Operation Manual
1
3
Hold left mouse button
4
1
Hold left mouse button
3
4
1
2
3
4
1
2
3
4
