HOTMOUSE CURSOR IN PIP MODE

Hotmouse Cursor IN PIP MODE
Change active channel
Enable Hotmouse Cursor. Move the Hotmouse Cursor to the PiP-image of the channel you wish to activate
and press the left mouse button.
Note:
When the Hotmouse Cursor moves over a PiP-image, its appearance changes
(arrows, channel number).
Example: Switch from channel 2 to channel 3
2
Channel 2 is active
Vertical positioning of PiP images
Activate Hotmouse Cursor. Move the Hotmouse Cursor to the PiP-image area, hold down the left mouse
button and drag the PiPs to the desired vertical position.
Note:
As soon as the Hotmouse Cursor moves over a PiP image, its appearance changes
(arrows pointing in vertically).
Example: Move PiP images upward
2
SPLITMUX - Installation and Operation Manual
1
2
3
4
Channel 3 is selected.
1
2
3
4
HOTMOUSE
1
3
3
4
Channel 3 is active.
1
2
3
4
1
2
4
1
2
4
75
