Summary of Contents for NTI VOPEX-USBV-2
- Page 1 ® VOPEX Series VOPEX-USBV-2 USB Keyboard, Video, and Mouse Splitter/Hub Installation and Operation Manual MAN034 Rev Date 10/7/2004...
-
Page 2: Warranty Information
Warranty Information The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com information regarding repairs and/or returns. A return authorization number is required for all repairs/returns. COPYRIGHT Copyright ©... -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION................................1 LIMITATIONS .................................. 1 MATERIALS ..................................1 FEATURES AND FUNCTIONS............................2 INSTALLATION................................3 Monitor Connection..............................3 Mouse Connection............................... 3 Keyboard Connection ..............................3 CPU Connection ................................4 Hub Ports ..................................4 Power-Up ..................................4 OPERATION ................................... 5 Keyboard Command Mode............................ -
Page 4: Introduction
INTRODUCTION The VOPEX-USBV-2-HUB (VOPEX) is a USB KVM Splitter and 3-Port Hub. It enables the control of one USB enabled CPU through two separate USB keyboards, USB mice, and VGA monitors and it enables the connection of 3 additional USB devices (other than keyboards or mice). -
Page 5: Features And Functions
DEVICE 2 DEVICE 1 FEATURES AND FUNCTIONS Power Switch- to power up or power down the VOPEX-USBV-2. Power LED- for visual indication of splitter's power status Mode Status LED’s- for visual indication of splitter's operating mode Mode Switch- press to manually switch between operating modes... -
Page 6: Installation
Disconnect the mouse at the CPU and reconnect it to one of the female USB type A 'USER 1 DEVICES" ports on the VOPEX. Connect a second mouse (or optional USB extension cable NTI USB-A+A-5M) to the female USB type A "USER 2 DEVICES" ports on the VOPEX. -
Page 7: Cpu Connection
Connect the male 15HD connector end of the VEXT-3 into the CPU’s video port. (See Fig. 2) Connect the female 15HD connector end of the VEXT-3 into the "VIDEO" port on the VOPEX. Rear View of VOPEX-USBV-2 VIDEO MONITOR 1... -
Page 8: Operation
NTI BRANDNAME AND DESCRIPTON OPERATION Mode Selection The VOPEX comes equipped with four (4) modes of operation. To manually toggle between modes, depress the MODE button once each time a mode change is desired. The VOPEX will cycle through the 4 modes of operation, then return to the first mode (1 to 2, 2 to 3, 3 to 4, 4 to 1). -
Page 9: Mice And Trackballs With Macs
NTI BRANDNAME AND DESCRIPTON Mice and Trackballs with MACs The VOPEX can be configured to enable full functionality between mice and trackballs having two or more buttons and a USB MAC CPU. By default, the CPU port on the VOPEX is configured for use with a WINDOWS or SUN CPU and has no special translation for using multi-function mice and trackballs when a MAC CPU is connected. -
Page 10: Specifications
NTI BRANDNAME AND DESCRIPTON SPECIFICATIONS Size: Each unit is 8.5”W x 6”D x 2.6”H Power: Powered by 120 or 240VAC @ 50 or 60Hz-5VDC/2.0A AC Adapter Connections: 15HD VGA & SGA compatible USB Type A female device connectors USB Type B female CPU connector...
