REAR PANEL (continued)
6. RS 232 / RJ45 control port
Connect external serial control devices to this RJ-45 port to operate SPLITMUX remotely, e.g. connect to
this port to access the OSD menu from a computer using the ConfDev device configuration tool (see page 89).
The serial RS 232 port is also used for firmware updates (see page 93).
7. USB for keyboard, mouse, touch or trackball (console)
Two USB ports allow connecting keyboard, mouse, touch screen or trackball.
Using a USB-Hub, you can connect multiple keyboards and mice.
They will work in share mode with an inactivity timeout of 3 seconds.
8. USB or PS2 keyboard and mouse (computer)
Each computer can be connected with PS/2 or USB-B for keyboard and mouse.
. Four transparent high-speed USB 2.0 ports
USB devices (printer, memory stick, finger printer, 3D mouse) are connected to the four transparent USB ports.
This transparent USB 2.0 matrix switches USB 2.0 periphals to computers connected to SPLITMUX.
