VOPEX-C5SVA/C5SV-x
S-Video/Audio or S-Video Only
Installation and Operation Manual
1275 Danner Dr
Tel:330-562-7070
Aurora, OH 44202
Fax:330-562-1999
www.nti1.com
TM
XTENDEX
Splitter/Extender
Series
(Receiver not included)
Manual 054 Rev. 12/03/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTI VOPEX VOPEX-C5SV-x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NTI NTI VOPEX VOPEX-C5SV-x

  • Page 1 NETWORK TECHNOLOGIES INCORPORATED VOPEX-C5SVA/C5SV-x S-Video/Audio or S-Video Only Installation and Operation Manual 1275 Danner Dr Tel:330-562-7070 Aurora, OH 44202 Fax:330-562-1999 www.nti1.com XTENDEX Series Splitter/Extender (Receiver not included) Manual 054 Rev. 12/03/03...
  • Page 2: Warranty Information

    A return authorization number is required for all repairs/returns. Copyright © 2003 by Network Technologies Inc, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
  • Page 3: Table Of Contents

    Introduction... 1 Materials ... 1 Features and Functions... 2 Limitations ... 3 Preparation for Installation ... 3 Installation ... 4 VOPEX-C5SVA-x and VOPEX-C5SV-x ... 4 ST-C5SVA-R-600 and ST-C5SV-R-600 Receiver ... 6 Plug-in and Power Up ... 7 Video Quality ... 8 Video Quality Adjustment for VOPEX-C5SVA-x ...
  • Page 4: Introduction

    Introduction Introduction The XTENDEX Series VOPEX-C5SVA-x Cat5 Video/Audio Splitter/Extender is designed to enable one S-Video/Audio source to be viewed and heard in 4, 8, or 16 different remote locations. Remote monitors and stereo speakers can be located as much as 600 feet away from the source via Category 5 unshielded twisted- pair cable.
  • Page 5: Features And Functions

    N T I X T E N D E X N e t w o r k T e c h n o l o g i e s I n c Features and Functions Features and Functions 1. S-Video Connector- 4-pin miniDIN female- for connecting the cable from the video source 2.
  • Page 6: Limitations

    Limitations Limitations • The audio input of the VOPEX-C5SVA-x S-Video/Audio Splitter/Extender is compatible with the following standard CPU audio outputs: • Line out - typically lime green in color • Speaker out- typically orange in color • Headphone out- typically located on the CD-ROM •...
  • Page 7: Installation

    Installation Installation VOPEX-C5SVA-x and VOPEX-C5SV-x Note: VOPEX-C5SV-x S-Video Only Splitter/Extender does not have audio support. support is not present, please disregard all audio references. 1. Make connections between the VOPEX-C5SVA-x and the audio and video source(s). (See Fig. 1.) a) Connect a 4-pin miniDIN cable end of a SVEXT-6-MM to the VGA connector on the back of the video source.
  • Page 8: Figure 2- Connect Local User Components And Cat5 Cable To Vopex-C5Sva-8

    2. Connect the local user to the VOPEX-C5SVA-x (see Fig. 2) Connect one end of another SVEXT-xx-MM cable to the 4-pin miniDIN female connector marked "S-Vout" on the VOPEX-C5SVA-x. Connect the other end of the SVEXT-xx-MM cable to the 4-pin miniDIN female connector on the local s-video display.
  • Page 9: St-C5Sva-R-600 And St-C5Sv-R-600 Receiver

    ST-C5SVA-R-600 and ST-C5SV-R-600 Receiver Note: This section is applicable to both models of Receiver except for step 4. When installing ST-C5SV- R-600 Receivers (no audio support), disregard step 4. 1. Position a ST-C5SVA-R-600 Receiver such that the CAT5 cable, the SVEXT-xx-MM cable, speaker cable, and the AC adapter power connector can each reach the Receiver comfortably.
  • Page 10: Plug-In And Power Up

    Plug-in and Power Up Plug-in and Power up 1. Plug the power cord from each monitor and the power supply for each set of stereo speakers into a power outlet. Connect the 5VDC AC adapter power connector to the 5VDC port on the VOPEX-C5SVA-x. Make sure the power connector goes into the port all the way.
  • Page 11: Video Quality

    Note: Video quality adjustment of the VOPEX-C5SV-x is performed manually at the Receiver. See "Video Quality Adjustment for VOPEX-C5SV-x" below. Network Technologies Inc Figure 5- Video Adjust button for manual video quality adjustment Video quality may need to be re-adjusted if any of the following situations occur: •...
  • Page 12: Technical Specifications

    Side view of ST-C5SV-600 Receiver Figure 6- Video quality adjustment buttons on ST-C5SV-600 Receiver Technical Specifications Technical Specifications Maximum Resolution (refresh frequency 60Hz) Video Compatibility Video Quality Adjustment (VOPEX-C5SVA only) Video Coupling Video Connectors Video Maximum I/O Levels Input / Output Impedance Audio Connectors Signal Type Audio Frequency Response...
  • Page 13: Interconnection Cable Wiring Method

    Troubleshooting Troubleshooting Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise.
  • Page 14 Problem Cause • Video picture is not All Video Cables are not firmly sharp or is smeared seated. • CAT5 cable is too long. • The CAT5 cable is not properly connected. • A cabling change has been made while the system was powered.
