Communications Commands

Host Protocol
If selecting one of the options from 0 to 4 (Point-to-Point, Point-to-Point with
RTS/CTS, Point-to-Point with XON/XOFF, Point-to-Point with XON/XOFF
and RTS/CTS, or Polling Mode D), use this format:
Format: <Kfprotocol>
protocol:
0 = Point-to-Point
1 = Point-to-Point with RTS/CTS
2 = Point-to-Point with XON/XOFF
3 = Point-to-Point
with XON/XOFF and RTS/CTS
Example: To change the Protocol to Polling Mode D, enter <Kf4>.
If selecting Multidrop (5), you must define an address and append it to the
command string.
Format: <Kf5protocol,address>
protocol:
5 = Multidrop
Example: To change the Protocol to Multidrop with an address of 33, enter
<Kf5,33>.
If selecting User Defined (6) or User Defined Multidrop (7), you complete
the format by either choosing new parameters or concatenating unchanged
data fields (separate by commas).
For User Defined, you first select Point-to-Point <Kf0> and then User
Defined <Kf6...>. For user Defined Multidrop, you first select Multidrop
<Kf5>, then User Defined Multidrop <Kf7...>.
MS-7100/7180 Industrial Scanner User's Manual

Communications Commands

4 = Polling Mode D
5 = Multidrop
(requires address)
6 = User Defined
7 = User Defined Multidrop
address:
Any number from
1 to 50
3-5
