Serial Verification
<KSecho K command,beep on K command,control character output>
echo K command: beep on K command:
0 = Disabled 0 = Disabled
1 = Enabled 1 = Enabled
Example: To enable Echo K Command, Beep on K command, and Control
Character Output, enter <KS1,1,1>.
User Outputs Status Request
Format: <KG?4>
Returns status of each command in the group.

Raster Setup Commands

Format: <KRstatus,top offset,bottom offset,motor speed,raster on/off>
status:
0 = Disabled
1 = Enabled
bottom offset in degrees:
Any number from 0 to 45. Default is 45.
raster on/off:
0 = Disabled 1 = Enabled
Example: To set Raster Arc to 35°, Sweeps per Second to 10, and not
change Raster On/Off, enter <KR1,5,40,10>.
See "Raster Setup Menu" on page
MS-7100/7180 Industrial Scanner User's Manual

Raster Setup Commands

control character output:
0 = Control
1 = Hex
top offset in degrees:
Any number from 0 to 45.
Default is 0.
motor speed in sweeps per second:
Any number from 0 to 135. Default is 14.
2-37.
3-17
