User Outputs Commands

Beeper
Format: <Kuoutput,volume>
beeper status:
0 = Disabled
1 = On Good
2 = On Noread
Example: To set the beeper for On Noread and set the beeper volume to
Level 5, enter <Ku2,4>.
Relay Settings
Format: <Kvrelay--output #1 setting,TTL--output #2 setting>
relay--output #1 setting:
0 = Good Match
1 = Mismatch
2 = Noread
3 = Mismatch or Noread
Example: To change Relay--Output #1 to Noread, enter <Kv2>.
See "Relay Settings," on page
New Master Pin
Format: <Kzstatus>
status:
0 = Disabled
Example: To enable New Master Pin, enter <Kz1>.
Laser On/Off
Format: <KCstatus>
status:
0 = Disabled
Example: To enable Laser On/Off, enter <KC1>.
MS-7100/7180 Industrial Scanner User's Manual

User Outputs Commands

beeper volume:
0 = Level 1 3 = Level 4
1 = Level 2 4 = Level 5
2 = Level 3
TTL--output #2 setting:
0 = Good Match
1 = Mismatch
2 = Noread
3 = Mismatch or Noread
2-32.
1 = Enabled
1 = Enabled
3-15
