Operations Commands

Triggering Mode
Format: <Kgmode>
mode:
0 = Continuous Read
1 = Continuous Read 1 Output
2 = External Level
Example: To select External Edge, enter <Kg3>.
End of Read Cycle
Format: <Khend of read cycle, timeout>
end of read cycle:
0 = Timeout
1 = New Trigger
2 = Timeout & New Trigger
Example: To select Timeout and change the timeout value to 6 seconds,
enter <Kh0,600>.
Serial Trigger Character
Format: <Kitrigger character>
serial trigger character:
Enter any available ASCII character (see
Example: To define the Serial Trigger Character as a lowercase c, enter
<Kic>.
External Trigger Polarity
Format: <Kjpolarity>
polarity:
0 = Negative
Example: To change External Trigger Polarity to Negative, enter <Kj0>.
1. Selecting a serial trigger character that is also an operational command will make that operational com-
mand unavailable, although the trigger will work. For example, an uppercase C cannot be used as a serial
trigger character because it is the operational command for Enter Read Rate Test. However, a lowercase c
could be used without interfering with the read rate test.
MS-7100/7180 Industrial Scanner User's Manual

Operations Commands

3 = External Edge
4 = Serial Data
5 = Serial Data & Edge
timeout:
When enabled, the default is one second. To
change, enter a number between 0 and 65535.
(This number is in 10 ms increments and is
derived by multiplying the desired number of sec-
onds by 100.)
1
table A-1 on page A-5). Default is ^].
1 = Positive
3-9
