Table 3-1 Summary of Serial Configuration Commands
Function Cmd Command Title
Ku Beeper
Kv Relay Settings
Kz New Master Pin
KC Laser On/Off
KD Reverse Video
User Kw Output Polarity
Outputs
Kx Output Pulse Width
KE Command Start Character
KG Serial Verification
KY Partial Ouput
KG?4 User Output Status Request <KG?
Raster KR Raster Setup
Serial Configuration Command Format
Format: <Kparameterdata,data,...etc.><initializing command>
Where:
• Less than < and greater than > symbols are included as part of the com-
mands.
• "parameter," as used here, are those character(s) that precede the data.
• the "initializing command" <Z> is sent after configuration is complete to
reset and save for power up. If you want to reset without saving for power
up, send the command alone.
For example, the following command enables UPC: <Ks1>.
When using serial configuration commands, note also the following conventions:
• Parameters and data are "case sensitive." That is, characters must be
entered as upper or lower case, as specified.
• All data fields (except the last) must be followed by a comma (without a space).
• If there is no change in a given field, then commas can be entered alone,
or with the existing data (for example, <Ka,,,0> or <Ka4,1,0,0>).
1. Commands that effect Communications are unique. See
effect communications" on page 3-4
MS-7100/7180 Industrial Scanner User's Manual
Summary of Serial Configuration Commands
Format
<Ku
status,volume>
<Kv relay--output #1 setting,TTL--output #2 setting
<Kz status >
<KC >
status
<KD status>
<Kw >
mode
<Kx number >
<KE ASCII character>
<KS
echo K command,beep on K command,control char-
acter output>
<KY status,start position,partial length>
>
4
<KR status,top offset,bottom offset,motor speed,raster on/off>
1
"Initializing serial configuration commands that
for definitions and examples.
>
