Chapter
2
Entering the Menu Configuration Program .......................................... 2-2
Using the Menu Configuration Program .............................................. 2-2
Saving Menu Changes ........................................................................ 2-4
Loss of Communications ..................................................................... 2-4
Defining Special Characters ............................................................... 2-4
Communications Menu ........................................................................ 2-5
Operations Menu ............................................................................... 2-12
Code Types Menu.............................................................................. 2-22
User Outputs Menu............................................................................ 2-31
Raster Setup Menu ............................................................................ 2-37
This chapter describes how to configure the MS-7100/7180 scanner with on
screen menu commands from a host or auxiliary terminal.
All keystrokes are in bold typeface.
Default parameters in the menu structures are also in bold typeface.
All of these parameters, with the exception of Full Screens, can also be
changed by serial commands (see
Communicating with an ASCII Terminal
The scanner communicates in full duplex, terminal mode with no hand-
shake. It also recognizes carriage returns and line feeds.
The host or ASCII terminal must match the following default settings
before any communication can take place: 9600 Baud Rate, Seven
Data Bits, Even Parity, and One Stop Bit.
MS-7100/7180 Industrial Scanner User's Manual
Menu
Configuration
Chapter Contents
Chapter 3, "Serial Configuration").
2-1
