Communications Commands
Protocol
If selecting one of the options form 0 to 4 (Point-to-Point, Point-to-Point with
RTS/CTS, Point-to-Point with XON/XOFF, Point-to-Point with RTS/CTS and
XON/XOFF, or Polling Mode D), use this format:
Format: <Kfprotocol>
protocol:
0 = Point-to-Point
1 = Point-to-Point with RTS/CTS
2 = Point-to-Point with XON/XOFF
3 = Point-to-Point with RTS/CTS
& XON/XOFF
Example: To change the Protocol to Polling Mode D, enter <Kf4>.
If selecting Multidrop (5), you must define an address and append it to the
command string.
Format: <Kf5protocol,address>
protocol:
5 = Multidrop
Example: To change the Protocol to Multidrop with an address of 33, enter
<Kf5,33>.
If selecting User Defined (6) or User Defined Multidrop (7), complete the for-
mat by either choosing new parameters or concatenating unchanged data
fields (separate by commas).
Tip: For User Defined, first select Point-to-Point <Kf0> and then User Defined
<Kf6...>. For user Defined Multidrop, first select Multidrop <Kf5>, then User
Defined Multidrop <Kf7...>.
MS-610 Scanner User's Manual
Communications Commands
4 = Polling Mode D
5 = Multidrop (requires address)
6 = User Defined
7 = User Defined Multidrop
address:
Any number from
1 to 50
3-5
