Application Mode

From EZ Mode, you can click on the App Mode button to access specific configuration
menus, Utilities tools, Camera setup, Output Format options, and a Terminal window
where serial commands can be entered.
Note: The App Mode and EZ Mode buttons appear in the same position to allow easy
switching between these primary modes.
Click this icon to
return to EZ Mode.
Note: For specific information on any of the icons shown above in the operations bar or
configuration bar, see the corresponding chapters in this manual.
MS-4 Imager User's Manual
Camera Setup, advanced
Calibration, Configuration
Database.
Menu toolbar.
Click the Configuration icon to return to full
App Mode view from Camera, Terminal,
Utilities, or Output Format.
Click Capture and Decode to
read the symbol in the field of
view, and to see a high resolution
image capture of the symbol.
Decoded symbol data
is shown in this table.
Click here to open
the Terminal view.
Click on icons in this row to
access configuration trees
like the one shown here.
Using ESP
Click here for
Ordered Output
and Output Format
features.
