Serial Configuration Commands
Appendix C — Serial Configuration Commands
Communications
Host Port Connections
Auxiliary Port Connections
RS-422 Status
Host Port Protocol
Preamble
Postamble
Response Timeout
LRC
Auxiliary Port System Data Status
ACK/NAK Options
Polling Mode Options
USB HID Reports
Autoconfiguration Daisy Chain
Calibration
Calibration Options
Autocalibrate
Read Cycle
Trigger Mode/Duration
Serial Trigger Character
External Trigger State
End of Read Cycle
Minimum Good Reads
Multisymbol
Start Trigger Character
Stop Trigger Character
Capture Mode
Capture Timing
Image Storage
IP Timeout
Symbologies
Narrow Margins/Symbology ID
Background Color
Composite
Code 39
A-6
<K100,baud rate,parity,stop bits,data bits>
<K101,aux port mode,baud rate,parity,stop bits,data bits,daisy
chain ID status,daisy chain ID>
<K102,status>
<K140,protocol,address>
<K141,status,preamble characters>
<K142,status,postamble characters>
<K143,response timeout>
<K145,status>
<K146,aux status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K149,Microscan HID IN report status,keyboard IN report status>
<K150DAISY>
<K529,gain,shutter speed,focus position,symbol type,WOI framing,
WOI margin,line scan height>
<@CAL>
<K200,trigger mode,trigger filter duration>
<K201,serial trigger character>
<K202,external trigger state>
<K220,end of read cycle,read cycle timeout>
<K221,minimum good reads>
<K222,number of symbols,multisymbol separator>
<K229,start character>
<K230,stop character>
<K241,capture mode,number of captures,rapid capture mode>
<K242,time before first capture,time between first and second
captures,,,,,,,,time between seventh and eighth captures>
<K244,image storage type,image store mode>
<K245,image processing timeout>
<K450,narrow margin status,symbology identifier status>
<K451,background color>
<K453,symbology status,separator status,separator>
<K470,status,check digit status,check digit output status,large
intercharacter gap,fixed symbol length status,fixed symbol
length,full ASCII set>
MS-4 Imager User's Manual
