Time Between Captures - Microscan MS-4 User Manual

Time Between Captures

Usage: This is useful in applications where more than one symbol can appear
during a single read cycle (multisymbol), or where line speeds are slow
enough that captured frames might overlap or miss a symbol.
Definition: A time delay can be inserted between individual frame captures in Rapid
Capture Mode.
Serial Cmd: <K242,time before 1st
2,...time7]
Entering 0s will result in no time between captures.
Entering a different value in each field will vary the time delays accordingly.
Note: You must enter time values along with comma separators for each
field you want to change. If you omit fields, or enter only commas, the fields
will remain as previously set.
Default: 0
Options: 0 to 65535 (2.097 seconds, in 32
Note: Number of Captures and number of frame delays (Time Between Captures) must
be the same.
Start of Read Cycle
Diagram A
Diagram B
MS-4 Imager User's Manual
capture,time between captures
µS increments)
Time Delay Between Captures = 0
1 2 3 4 5
Time Delay Between Captures varies.
Read Cycle
[time 1,time
End of
Read Cycle
5-21
