Timed Capture
Usage:
Timed Capture is useful in fast-moving applications in which symbols are
only in the field of view for a short time and precise timing is required.
Definition:
In Timed Rapid Capture, decoding occurs independent of and simultaneous
with capturing, thus allowing precise timing or no delay at all between
captures.
Also, consecutive captures are regarded as the same symbol if the output
data is the same.
Start of Read Cycle
Diagram A
Time Before First Capture
Diagram B
5-18
No Time Delay Between Captures
n
Time Delay Between Captures
Processing
End of
read cycle
End of
read cycle
MS-4 Imager User's Manual
