Application Mode

Application Mode gives you access to a robust configuration environment, including
tree controls that let you make precise changes to operation parameters, and graphic
interfaces that make configuring your imager easy and intuitive.
Click here to
Click on this icon to
return to
return to this view from
Utilities or Terminal.
EZ Mode.
Menu Click these buttons to
toolbar Send and Receive
commands or switch
reader models.
Note: For specific information on any of the icons shown above in the operations bar or
configuration bar, see corresponding chapters in this manual.
MS-Q Imager User's Manual
Click here for imager button
optimization, configuration,
and configuration summary.
Click here Click here for Image
to open Upload, Batch Files,
Terminal. and Firmware.
Click these tabs to access
configuration tree controls.
Assign Preamble and Postamble characters
using the simple interface shown above.
Using ESP
2-3
