• For the customers in European countries other than the
United Kingdom
Part number 1-551-631-61 (250 V, 10 A, about 2.0 m)
RCC-G5 9-pin Remote Control Cable
RM-280 Remote Edit Controller
VMC-IL6635B/IL6615B i.LINK Cable (6P-4P, without
lock)
VMC-IL4635B/IL4616B i.LINK Cable (6P-6P, without
lock)
PFD23/23A Professional Disc
PFD50DLA Dual-layer Professional Disc
BP-L80S Battery Pack
BP-GL95 Battery Pack
BKP-L551 Battery Adaptor
PDBK-201 TS Optional Board
Design and specifications are subject to change without
notice.
Notes
• Always make a test recording, and verify that it was
recorded successfully. SONY WILL NOT BE
LIABLE FOR DAMAGES OF ANY KIND
INCLUDING, BUT NOT LIMITED TO,
COMPENSATION OR REIMBURSEMENT ON
ACCOUNT OF FAILURE OF THIS UNIT OR ITS
RECORDING MEDIA, EXTERNAL STORAGE
SYSTEMS OR ANY OTHER MEDIA OR
STORAGE SYSTEMS TO RECORD CONTENT
OF ANY TYPE.
• Always verify that the unit is operating properly
before use. SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING, BUT
NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE
LOSS OF PRESENT OR PROSPECTIVE PROFITS
DUE TO FAILURE OF THIS UNIT, EITHER
DURING THE WARRANTY PERIOD OR AFTER
EXPIRATION OF THE WARRANTY, OR FOR
ANY OTHER REASON WHATSOEVER.
Using PDZ-1 Proxy
Browsing Software
When a computer with the PDZ-1 Proxy Browsing
Software installed is connected to this unit, you can
transfer the proxy AV data and metadata files recorded on
a disc to the computer. On the computer side, PDZ-1
enables you to browse the proxy AV data, add or modify
metadata (titles, comments, essence marks, etc.), or create
a clip list.
The modified metadata and the created clip list can then be
written back to the disc loaded in this unit.
For more information about PDZ-1 functions and
operations, refer to the PDZ-1 help.
System requirements
The following are required to use PDZ-1.
• Computer: PC with Intel Pentium M CPU, at least 1 GHz
(installed memory: at least 512 MB)
• Operating system: Microsoft Windows XP Professional
SP2 or higher, or Windows Vista Ultimate/Business
(32-bit)
• Web browser: Internet Explorer 6.0 SP1 or higher
• DirectX: DirectX 8.1b or higher
To install PDZ-1
Insert the supplied CD-ROM (PDZ-1 Proxy Browsing
Software) in the CD-ROM drive of the computer and
execute the Setup.exe file, then follow the installation
instructions.
For details, refer to the ReadMe file contained on the
CDROM disc.
Notes
• Make sure that the hard disk drive on which the work
folder to store the material transferred from this unit has
adequate free space.
• To transfer files between the computer and this unit
requires this unit's IP address and other network-related
settings to be made.
For details of the network-related settings, see "To change
network settings" (page 107).

Using PDZ-1 Proxy Browsing Software
