• Item names are the names which appear on an external
monitor to which the output of the COMPOSITE
OUTPUT 2 (SUPER) connector, the SDSDI OUTPUT 2
(SUPER) connector, or the HDSDI OUTPUT 2
(SUPER) connector is input.
• An abbreviated name appears in the time data display
section when you press the NEXT button.
Item number Item name
101 SELECTION FOR SEARCH DIAL
ENABLE
105 REFERENCE SYSTEM ALARM
107 REC INHIBIT LAMP FLASHING
108 AUTO EE SELECT
109 FORCED EE WHEN DISC UNLOAD When "off" is selected in menu item 108, during disc loading/unloading
114 AUDIO MONITOR OUTPUT LEVEL
118 KEY INHIBIT SWITCH EFFECTIVE
AREA
Sub-item
1 FUNCTION-KEY
2 CONTROL PANEL
119 VARIABLE SPEED LIMIT IN KEY
130 DISPLAY DIMMER CONTROL
Menu items in the 100s, relating to the control panels
Settings
Select how the unit enters the shuttle, jog, or variable speed mode.
dial (dial direct): Press the SHUTTLE/JOG or VAR/JOG button or,
except during recording/editing, turn the jog dial or shuttle dial.
key (via search key): Press the SHUTTLE/JOG or VAR/JOG button.
Select whether or not to display a warning when the reference video
signal is not supplied or is out of phase with the input video signal.
off: No warning.
on: Flash the STOP button as a warning.
Select whether or not to flash the REC INHI indicator when recording is
prevented (see "REC INHI (recording inhibit) indicator" (page 19).
off: Light the REC INHI indicator.
on: Flash the REC INHI indicator.
When a disc is inserted and PB/EE on the HOME page of the function
menu is set to "EE", select the operation modes in which input video and
audio signals are automatically handled in E-E mode.
S/F/R (stop/f.fwd/f.rev): In stop/fast-forward/fast-reverse modes
stop: In stop mode
and when no disc is inserted, select whether o control the output signal
PB/EE setting.
on: Do not control (the signal is always an E-E signal).
off: Control.
Select whether or not to control the level of the audio signal output from
the AUDIO MONITOR R, L connectors with the LEVEL knob for the
PHONES jack.
var (variable): Control.
fixed: Do not control.
Select which buttons can be operated when the KEY INHI switch is set to
ON. The following sub-items control different sets of buttons
independently.
Select whether function buttons on the front panel are enabled.
dis (disable): Disabled.
ena (enable): Enabled.
Select operable switches and buttons on the front panel are enabled.
dis (disable): Disabled.
ena (enable): Enabled.
Select the playback speed range when carrying out playback in variable
speed mode from the front panel of this unit.
off (off (–1 to +2)): –1 to +2 times normal speed.
on (on ( 0 to +1)): 0 to +1 times normal speed.
Set the brightness of the indication on the display
10%, 25%, 50%, 75%, 100%
• The values in the Settings columns are the values which
appear in the time data display section. (The values may
appear in a different format on an external monitor. In
this case, the external monitor values are shown in
parentheses.) Underlined values are the factory defaults.
