1
Use the PUSH SET(S.SEL) knob or the V/MARK1
and v/MARK2 buttons to select the required item,
then press the PUSH SET(S.SEL) knob or the
SELECT function button (F2).
The sub-items of the selected item appears.
2
Select a sub-item with the same operation as step 1,
and use the PUSH SET (S.SEL) knob or the V/
MARK1 and v/MARK2 buttons to change the setting.
3
Press the PUSH SET(S.SEL) knob or the SELECT
function button (F2) to confirm the setting change.
4
Press the SAVE function button (F5).
The message "NOW SAVING..." appears on the video
monitor display, and "Saving..." appears in the time
data display area, while the new settings are saved in
memory. When the saving operation is completed, the
video monitor display and the time data display area
return to their normal indications.
To cancel changing a setting
Before pressing the SAVE function button (F5), press the
MENU button.
The menu disappears from the video monitor display,
without saving the new setting.
To change network settings
To change network settings, carry out step 1 in the
previous section, "To change a menu item setting" above,
to display the NETWORK menu item, then carry out the
following operations.
For details of the settings, consult your network
administrator.
When the IP address is assigned automatically
Note
Check that the network cable is connected to this unit
before carrying out the operation.
Follow the procedure as shown in previous section "To
change a menu item setting" to set maintenance menu item
M5: NETWORK >M50: DHCP to "ENABLE".
To check the assigned IP address
Select maintenance menu item M5: NETWORK
>M51: IP ADDRESS PRESET.
Note
If the IP address cannot be assigned, this is shown as
"000.000.000.000." In this case, consult the network
administrator.
To set the IP address
First set DHCP to "DISABLE" (see the previous section,
"When the IP address is assigned automatically").
1
Select maintenance menu item M5: NETWORK
>M51: IP ADDRESS PRESET.
2
Press the PUSH SET(S.SEL) knob.
The IP address appears, and the digit that can be
changed flashes.
3
Set the IP address.
To select a different digit to be changed
Use the B/IN and b/OUT buttons.
To change the value of a digit
Turn the PUSH SET(S.SEL) knob.
Turning clockwise increases the value, and turning
counterclockwise decreases the value.
The V/MARK1 and v/MARK2 buttons can be used.
To return to the factory default setting
Press the RESET/RETURN button.
4
When all digits are set, press the SAVE function
button (F5).
This returns to the NETWORK menu.
5
Repeat steps 1 to 4 as required, to set the subnet mask
and default gateway.
6
In the NETWORK menu, press the SAVE function
button (F5).
7
When the "NOW SAVING..." message vanishes,
power the unit off and then on again with the on/
standby button.
Setting the communications speed
Set the communications speed (LINK SPEED) and
communications method (DUPLEX) to match the network
environment.
For details of the operation, see "To change the settings of
menu items" (page 91).
107
Maintenance Menu
