Function menu settings

The following tables list the setting items on each page and
describe their setting values. Underlined values are the
factory defaults.
HOME page
Item Setting
F1: CHAR SEL Turns the display of character
information on the LCD monitor screen
and on an external monitor on and off.
ON: Character information on
OFF: Character information off
LCD: Character information on for the
LCD monitor only
F2: PB/EE Selects the type of video and audio
signals to output during fast forward,
rewind, stop, and standby.
PB: Playback signal
EE: E-E signal
F3: REC INHI Specifies whether to inhibit recording to
the disc.
OFF: Do not inhibit recording.
ON: Inhibit recording to the disc
according to the setting of setup
menu item 310 REC INHIBIT.
F4: CNTR SEL Selects the type of time data to display in
the time data display area.
TC: Timecode
COUNTER: Elapsed recording or
playback time
UB: User bits
F5: TCG SET • When CNTR SEL is set to "TC" ,
displays a screen where you can set
the initial value of the timecode
generated by the internal timecode
generator
• When CNTR SEL is set to "UB" ,
displays a screen where you can set
timecode user bits
F6: (Unassigned function button)
a) This is displayed only when TCG on page P4 TC of the function menu is
set to "INT", and PRST/RGN is set to "PRESET".
P1 VIDEO page
Item Setting
F1: V INPUT Selects the video input signal.
HDSDI: HDSDI signal
i.LINK: i.LINK signal (when optional
board is installed)
SG: Test signal from internal signal
generator (Normally this item is not
displayed. It appears when you hold
the button down for 3 seconds.)
a)
(see page 36).
a)
(see page 36).
Item Setting
F2: VID. PROC Selects the method used to control the
internal video signal processor and make
related settings.
LOCAL: Use the function menu to
change settings.
MENU: Use the setup menu to change
settings.
F3: VIDEO Sets the output level for HD/SD video
signals (range –∞ to +3 dB).
PRESET: Set the video signal output
level to a preset value, regardless of
manual setting.
Manual setting: While the setting value
is flashing, turn the PUSH SET
(S.SEL) knob to adjust the video
signal output level.
F4: CHROMA Sets the output level for HD/SD chroma
signals (range –∞ to +3 dB).
PRESET: Set the chroma signal output
level to a preset value, regardless of
manual setting.
Manual setting: While the setting value
is flashing, turn the PUSH SET
(S.SEL) knob to adjust the chroma
SETUP signal output level.
F5: HUE/CHRM Sets the hue (chroma phase).
PHS PRESET: Set the hue (chroma phase) to
a preset value, regardless of manual
setting.
Manual setting: While the setting value
is flashing, turn the PUSH SET
(S.SEL) knob to adjust the hue
(chroma phase) over the range
±30°.
F6: SETUP/ Sets the HD/SD output black setup level
BLACK or black level.
PRESET: Set the level to the preset
value, regardless of the manual
setting.
Manual setting: While the setting value
is flashing, turn the PUSH SET
(S.SEL) knob to set the black setup
level (in 59.94i mode) over the range
±30 IRE or the black level (in 50i
mode) over the range ±210 mV.
P2 AUDIO page
Item Setting
F1: A1 INPUT Selects the audio input signal to assign
to audio channel 1.
SDI: Audio signal embeded into SDI
signal
ANALOG1: Analog 1 audio signal
AES/EBU: Signal input to the DIGITAL
AUDIO(AES/EBU) IN 1/2 connectors
i.LINK: Audio signal embeded into
i.LINK input
SG: Test signal from internal signal
generator (Normally this item is not
displayed. It appears when you hold
the button down for 3 seconds.)
