EXT ER NAL SHO WER PO IN T
WARNING: Care should be taken when
using the external barbeque point.
Never barbeque next to an awning or tent.
WARNING: The caravan barbeque point
should only be used as an outlet point for
gas, never connect a gas bottle direct to the
outlet.
EXTERNAL SHOWER POINT
The external shower point if fitted comes
complete with a shower head assembly. It
uses the caravans existing hot and cold water
supply. Insert the shower hose assembly and
make a small turn anti clockwise which locks it
into place and turns on the water. Temperature
adjustment by turning the assembly using the
red and blue indicator.
166
To open the lid pull tab
on bottom edge and lift,
while pressing on centre
of flap.
CARAVANS WITH TV INLET IN
BATTERY BOX
Models equipped with TV points in the battery
box have the facility to take an external signal
and supply that signal to TV points within the
caravan.
Caravans equipped in this way feature a direct
link from the connection point in the battery
box, to an auxiliary connection point at the
primary TV position within the caravan. The
primary TV position is that which also features
an AV outlet plate (see later text).
The direct link can be used to:
1. Supply an external signal (caravan site TV
feed) to the primary TV position
- Connect the socket in the battery box
(on flying lead depending on model), with
a suitable lead, to the appropriate socket
on the caravan site supply post. As the
connector in the battery box is a screw on
'F-type' connector, an adaptor to convert
this to a 'push-on' co-ax connector, which
may be required, has been supplied with
your caravan.
