Page 1 Quality with Style Swift Caravans 2005 Warranty & Service Handbook...
Page 2: Table Of Contents
Warranty................2 What to do if you Require Assistance ......4 Annual Service/Inspection Record ........5 Specifications..............8 Wiring Diagrams – Road Lights ........13 Wiring Diagrams – Internal Wiring ........16 Bulb Replacement ............19 Change of Ownership CONTENTS...
Page 3: Warranty
• Carpets, lino and floor coverings including replacement light bulbs. door mats, shower mats. Dealers are not agents of Swift Group Limited, the manufacturer of Swift Group Also not covered under the first year are • Work surfaces, tables, and flaps.
Page 4 Warranty • Audio equipment including radios, • Replacement of parts which have Failure to notify Swift Group of a change of speakers, aerials and associated parts. reached the end of their effective ownership within 14 days of such a change working life because of age and/or will invalidate the warranty.
Page 5: What To Do If You Require Assistance
4. If you are calling the Customer Care Team, please avoid where possible, Mondays and lunch times. 5. Please be aware that the Swift Group cannot send parts direct from the factory. In all cases, without exception, your dealer must place the order for you.
Page 6: Annual Service/Inspection Record
Swift Group Service Centre at least once per year. It is important that the Owner’s Handbook is stamped on the appropriate page by the authorised Swift Group Service Centre. Failure to do this will invalidate the warranty and the transfer of the warranty on the change of ownership.
Page 7 Service/Inspection ANNUAL SERVICE/INSPECTION RECORD CARAVAN MODEL YEAR CHASSIS NUMBER 1st SERVICE 2nd SERVICE DATE: DATE: DEALER’S STAMP DEALER’S STAMP We certify that an annual service has been carried out in We certify that an annual service has been carried out in accordance with the handbook.
Page 8 5th SERVICE 6th SERVICE DATE: DATE: DEALER’S STAMP DEALER’S STAMP We certify that an annual service has been carried out in We certify that an annual service has been carried out in accordance with the handbook. accordance with the handbook. 7th SERVICE 8th SERVICE DATE:...
Page 9: Specifications
Specifications CHARISMA Berths Axles Internal Length (bed box height) 4.20m/13’9” 4.67m/15’4” 4.74m/15’7” 5.13m/16’10” 5.39m/17’8” Overall Width 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” Overall Height (inc. TV Aerial) 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” Overall Length 5.88m/19’3” 6.35m/20’10” 6.42m/21’1” 6.81m/22’4” 7.07m/23’2” Mass in Running Order (inc. tolerance) 1007kg/19.8cwt 1059kg/20.8cwt 1080kg/21.3cwt...
Page 10 Specifications CHARISMA Berths Axles Internal Length (bed box height) 5.13m/16’10” 5.23m/17’2” 5.23m/17’2” 5.50m/18’1” 6.27m/20’7” Overall Width 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” Overall Height (inc. TV Aerial) 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” 2.70m/8’10” Overall Length 6.81m/22’4” 6.91m/22’8” 6.91m/22’8” 7.18m/23’7” 7.95m/26’1” Mass in Running Order (inc. tolerance) 1138kg/22.4cwt 1173kg/23.1cwt 1153kg/22.7cwt*...
Page 11 Specifications CHALLENGER 490L Berths Axles Internal Length (bed box height) 4.61m/15’2” 4.61m/15’2” 4.61m/15’2” 5.39m/17’8” 5.39m/17’8” Overall Width 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” Overall Height (inc. TV Aerial) 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” Overall Length 6.30m/20’8” 6.30m/20’8” 6.30m/20’8” 7.08m/23’3” 7.08m/23’3” Mass in Running Order (inc. tolerance) 1084kg/21.3cwt 1092kg/21.5cwt 1123kg/22.1cwt...
Page 12 Specifications CHALLENGER 550L Berths Axles Internal Length (bed box height) 5.39m/17’8” 5.23m/17’2” 5.23m/17’2” 5.39m/17’8” 5.39m/17’8” Overall Width 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” Overall Height (inc. TV Aerial) 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” 2.76m/9’1” Overall Length 7.08m/23’3” 6.92m/22’8” 6.92m/22’8” 7.08m/23’3” 7.08m/23’3” Mass in Running Order (inc. tolerance) 1231kg/24.2cwt 1191kg/23.4cwt 1209kg/23.8cwt...
Page 13 Specifications CONQUEROR 580 Sal 630 Sal 640 Sal 645 Lux 650 Lux Berths 5 opt 6 Axles Internal Length (bed box height) 5.85m/19’2” 6.27m/20’7” 6.27m/20’7” 6.27m/20’7” 6.27m/20’7” Overall Width 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” 2.23m/7’4” Overall Height (inc. TV Aerial) 2.76m/9’1” 2.76m/9’1”...
Page 14: Wiring Diagrams - Road Lights
Wiring Diagrams CHARISMA RANGE 2005 - ROAD LIGHTS...
Page 15 Wiring Diagrams CHALLENGER RANGE 2005 - ROAD LIGHTS...
Page 16 Wiring Diagrams CONQUEROR RANGE 2005 - ROAD LIGHTS...
Page 17: Wiring Diagrams - Internal Wiring
Wiring Diagrams CHARISMA RANGE 2005 - 12V AND 230V...
Page 18 Wiring Diagrams CHALLENGER RANGE 2005 - 12V AND 230V...
Page 19 Wiring Diagrams CONQUEROR RANGE 2005 - 12V AND 230V...
Page 20: Bulb Replacement
Bulb Replacement TYPE RATING CHARISMA CHALLENGER CONQUEROR ROAD LIGHTS ✓ ✓ ✓ Front marker lights 12v 3w ✓ ✓ ✓ Side marker 12v 5w ✓ ✓ ✓ Reversing light P21W 12v 21w ✓ ✓ ✓ Rear indicator light PY21W Orange bulb 12v 21w ✓...
Page 21 NOTIFICATION OF CHANGE OF OWNERSHIP If you sell your caravan, please notify the change of ownership by completing this page, detaching it and sending it to: Swift Group Ltd., Dunswell Road, Cottingham, East Yorkshire, HU16 4JX. DETAILS OF CARAVAN: Model:...
Page 22 NCC Approved All Swift Group models have been certified by the National Caravan Council for compliance with stringent European Standards, British Legislation and industry set Codes of Practice specifically relating to health and safety issues. The approval process covers the testing and inspection of critical areas of the product from fire safety, weights and dimensions, to gas, electrics and ventilation.
Page 23 Quality with Style Swift Caravans, Dunswell Road, Cottingham, East Yorkshire HU16 4JX. Telephone: 01482 875740 Fax: 01482 840082 email: enquiry@swiftleisure.co.uk web site: www.swiftcaravans.co.uk Issued September 2004 1055917...
