- Page 1 Swift Escape 664 MANUAL Page...
-
Page 2: Technical Details
TECHNICAL DETAILS Seat Belts: 4 Berths: 4 Length: 6.72m (22.1 Ft) Width: 2.31m (7.7 Ft) Height: 2.91m (9.7 Ft) Weight: 3500Kg Bed Sizes Front Double: 6' 10" x 4' 0" / 3' 0" Rear Fixed Double: 6' 2" x 4' 2” The 240v sockets in the motorhome only work when motorhome is connected to a 240v power supply TV and lights will work off the Leisure battery If wild camping Heating , hot water , and cooking all work off the GAS. -
Page 3: Water Pump
WATER PUMP The command panel powers the Motorhome, on entering the Motorhome push the main button, the LED panel will light up the Touch Screen. The Water Pump is the Tap sign on the panel. Press this it will turn Blue and you will hear the pump running. - Page 4 On entering the motorhome Turn on the power by pushing the main button on the command Panel In the Swift Motorhomes the LED panel will light up. BEFORE OPERATING THE TRUMA PANEL select GAS or Electric and power up the Motorhome...
- Page 5 OPERATING INSTRUCTIONS Display and operating elements Rotary push button The rotary push button (8) is used to select and change set points and parameters; it is then tapped to save the values. Selected menu items flash. Turn clockwise • The menu is scrolled through from left to right .
- Page 6 Start-up Select energy mode Start/Stand-by screen. When the control panel is connected to the • Use the rotary push button to select the icon in power supply, after a few seconds a start screen the menu line. is displayed. • Tap the button to go to the setting level.
- Page 7 MOTORHOME FRIDGE OPERATION The fridge will not run off the motorhome leisure battery, this would drain the battery very quickly. The fridge will operate in 3 modes • Engine Battery: this is used to keep the fridge cool while traveling if the gas is turned off. •...
- Page 8 Example If the engine is turned on and the fridge is in auto it will move to the battery sign. If the Gas is left on for traveling push the button from Auto to Gas. This will stop the fridge looking for two sources, Battery, and Gas.
-
Page 9: External Equipment
EXTERNAL EQUIPMENT Diesel valve (Use ignition key) Gas Bottle, gas bottle Key, power cable, water Hose Toilet chemical for toilet Cassette Gas Bottle with on off valve and Safety trip switches. If no gas supply to the Motorhome make sure Main Valve Is Open, then Press the Green Trip Button Fresh Water Hose Bicycle rack... - Page 10 Toilet cassette 240v electric hook up point Fresh Water filling point Before removing the toilet, Cassette make sure the lever on the toilet is in the closed Fresh and Grey water tank drain, controlled position. Do not try to force the cassette from the command panel.
-
Page 11: Internal Equipment
INTERNAL EQUIPMENT Front Seating area. Rear fixed double bed This converts to double bed Front Bed Make Up Under Bed Storage Slide out support to create bed, cushions must be turned over for mattress affect Page... - Page 12 Shower Shower and Toilet Before using the toilet, slide the lever to the right to open the cassette flap, slide the lever to the left when done Do not move Lever while sitting on the toilet Fly screens for every window Blinds for every window Page...
- Page 13 Gas cooker if the Gas is turned on and not Microwave Can only be used with 240V light within 5 seconds the safety trip will turn off the gas. To reset push the Green button on the Gas Bottle regulator Push igniter and turn selected burner if no Crockery Cupboard click from ignitor turn on command panel...
- Page 14 USB sockets by bed Cover for side windows stored above windows Mains sockets Fix with push on buttons TV and DVD will work on 240v and the leisure battery For nighttime privacy Page...
- Page 15 Close all other window blinds Pull to close windscreen blinds Slide from both sides Fully closed Page...
