Winterisation/Storage - Swift Tourer Owner's Handbook Manual

WI NT ER IS ATI ON
WINTERISATION
The Swift Group recommends the following
winterisation points for customers:
Servicing
Arrange (in advance) the yearly service and
habitation check, if the caravan's next service
is due while the vehicle is stored.
Electrical
If vehicle is being stored while connected to
230v Mains Hook-up:
• Ensure that the leisure battery is
connected and the 20A local fuse(s) is
connected.
• The isolator switch on PSU should be in
the 'ON' position, however. the control
panel should be switched 'OFF'.
• If Alde system is installed, there is a frost
protection setting, which can be used.
• Vehicles can be left in this condition
for extended periods, with the charger
operating to maintain the battery. However,
periodic maintenance and inspection is
recommended, this should include the
battery condition.
If vehicle is being stored not connected to
230v Mains Hook-up:
• Charge the leisure battery for 24 hours
prior to placing caravan in storage.
• Ensure the isolation button on PSU is in
the 'OFF' position.
• Ensure leisure battery is connected and
20A local fuse(s) is in place, if an alarm or
tracker device is fitted.
• The alarm / tracking device will eventually
drain the leisure battery - we recommend
regular (monthly) inspection / re-charging
of leisure battery via appropriate means.
A solar panel can be used to provide an
alternative power source and extend the
time between leisure battery requiring a
re-charge.
184
• Remove the leisure battery and store in a
dry place, if an alarm or tracker device is
not fitted.
• The battery should not be adversely
affected by winter temperatures but the
level of charge should be maintained to
maximise the life span of the battery. This
can be achieved using an automotive type
battery charger as and when required.
Gas system
• Ensure the gas supply is isolated at
the gas bottle, and ensure that the gas
manifold taps are off.
• Check the age and condition of the high
pressure gas hose and regulator, and
replace if required.
Appliances
Check the battery expiry date on the smoke
alarm and replace or remove as required.
• Ensure the fridge is turned off.
• Clean the inside of the fridge.
• Prop the fridge door open, and if possible,
the internal freezer compartment door for
ventilation.
• Fit fridge vent winter covers (if available).
• Ensure all hob / oven / microwave
surfaces are clean.
• If the caravan is going to be left connected
to 230v supply while not in use, ensure the
microwave is unplugged.
• Drain the toilet reservoir.
• Empty the toilet cassette.
• Leave toilet caps removed and apply acid-
free Vaseline or similar to the seals.
• Drain the toilet reservoir.
• Empty the toilet cassette - The Thetford
Cassette porta potti is easily winterised for
storage.
Empty the fresh water tank using the drain
tube / fresh water tank level indicator (level
