- Locate the primary TV position within the
caravan. At the 12V, TV and SAT socket,
connect your TV to the output from the
socket marked SAT with a suitable lead.
2. Connect an external satellite dish to a
decoder within the caravan. (The direct
link uses F-type interconnects throughout
to allow the decoder and dish to
communicate correctly)
- Connect the dish to the socket (or flying
lead) in the battery box with a suitable
lead. The F-type to co-ax adaptor should
not be used.
- Connect the dish input connection on the
decoder to the 'SAT' socket on the 12V,
TV and SAT socket located in the primary
TV location.
3. Supply a signal from within the caravan to
the exterior of the caravan
- Connect the output from your VCR,
DVD player or other device to the SAT
connection on the 12V, TV and SAT socket
at the primary TV position.
- Connect your receiving device (TV or
similar) to the socket in the battery box
with a suitable lead.
As can be seen from the simplified schematic,
when multiple TV locations are present in a
van, all of these receive signals from the TV
aerial connection box. Using adaptors and
link cables which are readily available, it may
be possible to re-direct a signal from the
'SAT' connection at the primary TV location,
up to the aerial connection box to be then
distributed to other TV positions within the
caravan. Please remember that as the number
of connections increases the quality of the
signal reduces.
Supplier fitted / supplied entertainment
equipment
Audio-visual equipment may have been fitted
by your dealer, or supplied with the caravan,
depending on the specification of the caravan.
Although not specific, below are details of the
types of equipment which would be fitted as
appropriate to the specification of the caravan:
S TATU S 530 / 550 T V /R A DIO A NT E NN A
CD/MP3/tuner with auxiliary input
Where provision has been made in the
furniture to install a head unit similar in
appearance to that fitted in the dashboard of
a car. The unit operates as a CD player and
FM/AM radio. In addition MP3 files stored on
a CD can be read and played by the unit. An
auxiliary input on the front of the unit allows
a separate MP3 player to be connected from
that player's headphone socket. (A separate
lead may be required).
Speakers mounted in the front locker of the
caravan are connected to this head unit for
a stereo sound output. A retractable AM/
FM aerial on the side of the caravan, enables
reception of radio stations.
STATUS 530 / 550 DIRECTIONAL
TV AND FM RADIO ANTENNA
(model dependant )
Firstly determine the approximate location
of the nearest transmitter and whether the
signals are horizontally or vertically polarized.
For assistance ask your site operator or check
antennas in the vicinity
1. Loosen the Mast Locking Collar and Wall
Bracket and raise the antenna. Turn the
mast to direct the Antenna towards the
TV transmitter.
The RED spot on the bottom of the mast
indicates the front of the Antenna.
2. When receiving vertically polarized signals,
rotate the winder anti-clockwise to cant
the antenna through 90°. The red / green
indicator, if present, indicates vertical or
horizontal orientation.
DO NOT over tighten or use undue force
on the winder.
3. Switch ON the Power Pack and the RED
LED will illuminate.
4. Check the gain control switch is set to
normal – NML.
167
