Bedding - Swift Tourer Owner's Handbook Manual

B ED D ING
5. Tune your television to the strongest
signal. You may need to adjust the
direction of the mast to achieve the best
quality picture.
6. Secure by tightening the Mast Locking
Collar and Wall Bracket
REMOVING THE ANTENNA
A permanently fitted Status can be easily
removed leaving only the Mounting Foot and
rubber gaiter.
1. Unplug the antenna from the Power Pack.
2. Loosen the Mast Locking Collar and
Wall Bracket and lift off whilst feeding out
the cable.
3. Push the Blanking Cap supplied into
place.
IMPORTANT – The Blanking Cap is a
temporary seal and is not for long term use.
3 x
3 x
WARNING: Always ensure the aerial is
lowered before driving off.
168

BEDDING

Sleeping bags and duvets can be compressed
into small spaces and can be ready to use in
minutes.
Fig. A
Gaiter
Mounting
Foot
Central
Sleeve
Fig. B
Mounting
Plate
Lower single beds assembly (Figs. A & B)
Foam Seal 1. Lower dinette table and place between the
recess in both seats.
2. Arrange seat cushions as appropriate.
