Zaxcom Deva User's Manual_______________________________________________________ Chapter 3
NOTE: Pressing this button does NOT do anything to the following settings: limiters, trim, delay.

Adjust Delay button

Pressing it displays the

High Pass (#) Hz button

To set the Highpass Frequency, perform the following:
1. Press the High Pass (#) Hz button
You are prompted to enter the highpass frequency in Hz.
2. Use the numeric keys to enter the frequency.
The valid range is 30 – 70 – 240 Hz.
3. Press High Pass (#) Hz button
This sets the frequency.

High Pass button Shortcuts

See: Common Data Entry Field Shortcuts List

Adjust Trim button

Pressing it displays the
(Analog / Digital) Input Delay page
(Analog / Digital) Input Trim page
99
{p.109}.
{p.159}
{p.111}.
