Chapter 3_______________________________________________________Zaxcom Deva User's Manual

Preset button

Pressing it allows you to save and recall up to five saved settings. Think of each preset as a page on which to write
the configuration.
To save a configuration, perform the following:
1) Move to the Preset # you want to build. Normally, the first to be built would be Preset 1.
2) If you have not previously saved anything into the preset, it will be a blank slate (pun intended). Establish all of
the required items for this preset.
3) If you need to establish any additional presets, repeat steps 1 & 2 for each additional configuration.
To load a configuration once it has been saved, simply press the Preset button until the number displayed is the
one you're expecting. At that point, examine the configuration; it will be as you had saved it. If, at any time, you
need to update the configuration, inset your changes, they are automatically saved.
NOTES: 1) The Limit column settings are not saved in a specific preset #.
(Analog / Digital) In Toggle button
Press it to select either analog or digital inputs. Selecting a box once enables it, selecting it again disables it.
(Pre- / Post-) Fader button
Pressing it allows you to choose whether each selection is pre- or post-fader. For example, you can record the
microphone on one channel of the Deva post-fader and on another pre-fader, so it is unaffected by the mix. (See
Table 3-4)
-MORE- button
Pressing it pages through the buttons displayed on the bottom of the page.
Clear All button
Pressing it removes all selections in the matrix and empties the page.
NOTES: 1) The Limit column settings are not cleared when this button is pressed.
Phase Invert button
Pressing it reverses the phase of the selected input. A reversed phase input appears with a bar over the letter
(A/D). (See
Limiter Settings button
Pressing it displays the

Output Limiting button

Pressing it displays an additional column on the right used to flag which tracks have limiting enabled. With it
displayed, pressing any of the boxes will turn ON limiting for that track, indicated by an X. Pressing it again turns
OFF limiting for that track. The one set of parameters under the Limiter Settings button is used by all of these
limiters.
2) The Output Routing settings are not saved in a specific preset #.
2) The Output Routing settings are not cleared when this button is pressed.
Table 3-4)
Output Limiter Settings page {p.51}.
48
