Chapter 3_______________________________________________________Zaxcom Deva User's Manual
HI SHELF
PEAKING

Notch (#) buttons

Pressing it toggles the notch filter On or Off.

Entry Mode button

Cycles through the following list to select which element of the band / notch is to be modified:
CHANNEL – Causes the appropriate EQ channel to be displayed.
LVL/FREQ – The following keys are active:
o 2 key – adds 0.4 to the Level field.
o 8 key – subtracts 0.4 from the Level field.
o 6 key – adds a variable step to the Freq field, depending on where in the value range and how long the key is
held.
o 4 key – subtracts a variable step from the Freq field, depending on where in the value range and how long the
key is held.
LVL
FREQ
Q
– sets the current band to a High Shelf filter
– sets the current band to a Peaking filter.
– Causes changes to be applied to the Level field.
– Causes changes to be applied to the Freq field.
– Causes changes to be applied to the Q field.
106
