Chapter 3_______________________________________________________Zaxcom Deva User's Manual
Headphone Volume page
Page purpose:
been assigned to a track.
How to get here:
(HEADPHONE button)
Page Notes
As long as the level is being adjusted, this page will continue to be displayed. As soon as the adjustments stop, or
were never done, a 3.5 second timer starts counting down. When it reaches zero, this page is closed.
Page Level Shortcuts
LEFT ARROW key (keyboard)
UP ARROW key (keyboard)
RIGHT ARROW key (keyboard) – increases the headphone volume by ~4 dB.
DOWN ARROW key (keyboard) – increases the headphone volume by ~4 dB.

Headphone Linear graphic fader

It is used to adjust the headphone audio level in lieu of Fader 8. The scale is in dB.
This page provides alternate access to adjust the headphone level and appears when Fader 8 has
Figure 3-72 Headphone Volume page
– decreases the headphone volume by ~4 dB.
– decreases the headphone volume by ~4 dB.
138
