Chapter 3_______________________________________________________Zaxcom Deva User's Manual

Timecode Displayed button

Generator – TC comes from the internal generator. The Generator T.C. field displays the running TC.
Disk
o While in Playback
o While in Playback and press Stop – TC at the point where playback will re-start (by pressing PLAY key)
o While in Record
o While in Record and press Stop
Gen Stop – TC comes from the Primary Drive or the playback source. The Generator T.C. field contains:
o While in Playback – TC at the current point in the Take.
o While in Record
o While in Stop
NOTE: When you want to see the start timecode after a Take has completed, use Disk here.

Timecode Run Mode button

Pressing it displays the

Frame Rate button

Pressing it cycles through the following timecode frame-rates: 23.98 (23.976), 24, 25, 29.97NDF, 29.97DF,
30NDF and 30DF.

Enter Timecode button

Pressing it loads the timecode generator with a specified value.
Enter Timecode button Shortcuts
See: Common Data Entry Field Shortcuts List

Enter User Bits button

Pressing it loads the user-bit store with a specified value.

Enter User-Bits button Shortcuts

See: Common Data Entry Field Shortcuts List
o F1 – F6 keys – are mapped to the hex letters A – F.

Increment User Bits button

Pressing it toggles between incrementing (On) and not incrementing (Off) the user-bits. When On, the Deva
increments the last digit in the user-bits each time you go into Record mode.
NOTE: When incrementing is turned ON, it will increment the entire length.

JAM T.C. button

Pressing it jams the internal timecode generator from an external source.

JAM U.B. button

Pressing it jams the internal user-bits store from an external source.

JAM Date button

Pressing it jams the internal user-bits store from the Deva's date, entered in the

JAM Time button

Pressing it jams the timecode generator from Deva's Time-of-Day clock, entered in the

DUAL RATE TIMECODE

A feature of the Deva allows it to sync to one timecode frame-rate and record another. For instance, you can
input 23.98 timecode from an HD camera and record 29.97 timecode derived from it. The two frame-rates will
be in perfect sync matching up at frame one of each second. Deva will hold perfect timecode sync even when
cycling power. Many other timecode clocks can gain or lose a frame each time power is cycled.
– TC comes from the file being recorded or played-back. The Generator T.C. field contains:
– TC at the current point in the Take.
– TC being recorded during the Take, as it happens.
– TC for the start of the last Take.
– TC being recorded during the Take, as it happens.
– Running TC coming from the internal generator.
Timecode Run Mode page {p.59}.
{p.159}
{p.159}, with the following exception(s):
58
Time/Date page {p.80}.
Time/Date page {p.80}.
