Zaxcom Deva User's Manual_______________________________________________________Chapter 9
Analog Inputs
Channel Count
Deva-5.8
Deva-16
Connector
Mic / Line
Line
Input Range
Mic-level
Line-level
Mic Power
Impedance
Mic-Level
Line-Level
ADC Bit-depth
ADC Dynamic Range
Clipping Level
Frequency Response
THD + Noise
Digital Inputs
Standard
Channel Count
Connector
Sample-rate Converters

Analog Outputs

Channel Count
Deva-5.8
Deva-16
Connector
Output Level
Clipping Level
DAC Bit-depth
DAC Dynamic Range
Impedance

Digital Outputs

Standard
Channel Count
Connector
Output Common Items
Source
Headphones
Connector
Dynamic Range
Impedance
Built-in Soundfield Decoder
Built-in M/S Decoder
Chapter 9 – Equipment Specifications
Hardware Based Parameters
8 x mic / line
8 x mic / line + 4 x line only
XLR-3F
10-pin Hirose
–56 dBu to –26 dBu
–10 dBu to +8 dBu
(on Mic input only) 48 VDC phantom (each 10 mA max)
10 k ohms
4 k ohms
24
117 dB
+28 dBu
20 Hz to 22 kHz (@ 48 kHz sampling-rate)
0.001%
AES3
4 pairs
mini DB-15
4 pairs
6 x balanced
7 x balanced + 1 x unbalanced
DB-25
0 dBu at –20 dBFS
+20 dBu
24
112 dB
600 ohms
AES3
4 pairs
mini DB-15
Mix/Direct (selectable)
1 x 1/4" stereo jack
112 dB
100 ohms (optimal)
Yes
Yes
