Zaxcom Deva User's Manual_______________________________________________________ Chapter 3

Level meter

It displays the current audio level for this channel. The view point for this meter is post trimmer and pre-fader.
The scale is dBFS.

Dynamics button

Pressing it displays the

EQ button

Pressing it displays the
NOTE: Unlike the Fusion-10, the Effects Package is included in both the Dva-5.8 and Deva-16.

BUS button

Pressing it displays the

Mix12 Input Trim Select button

Normal
Tx ZaxNet – Indicates any changes made to this channel's Mix-12 Input Trim knob will send a ZaxNet
Digital Input (#) – Dynamics page
Digital Input (#) – EQ page
Digital Input (#) – BUS page
– Indicates any changes made to this channel's Mix-12 Input Trim knob will affect Zaxcom's
preamp for this channel.
command to adjust this channel's transmitter pre-amp.
{p.102}.
{p.104}.
{p.107}.
101
