Zaxcom Deva User's Manual_______________________________________________________Chapter 9
Internal Mixer
Mixer Cross-points
Internal Processing
Effects (Optional)
Input Compressor
Type
Attack
Decay
Threshold
Ratio
Make-up Gain
Input Band Filter
Bands
Types
Level
Freq Range
Q
Input Notch Filter
Bands
Level
Freq Range
Q
Effects (Included)
Disk Limiter
Channel Count
Attack
Decay
Threshold
Ratio
Make-up Gain
Input Highpass Filter
Freq. Range
Input Delay
Time Range
Input Limiter
(parameters fixed)
Output Limiter
Attack
Decay
Threshold
Ratio
Make-up Gain
Recording
Track Count
Deva-5.8
Deva-16
Bit-depth
Primary Drive
Mirror Drive(s)
Sampling-rates (kHz)
Software Based Parameters
16 in / 24 out (pre-fader, post-fader, phase inversion)
32-bit floating point DSP
(A x 8, D x 8)
Soft Knee
1 to 100 ms
50 to 1000 ms
–60.0 to 0.0 dB
1.0:1 to 20.0:1
0.0 to 20.0 dB
(A x 8, D x 8)
3
LO SHELF, HI SHELF, PEAKING
-24.0 to +24.0 dB
30 Hz to 20 kHz
0.5 to 9.9
(A x 8, D x 8)
2
–24.0 to +24.0 dB
30 Hz to 20 kHz
0.5 to 9.9
Deva-5.8 (x 10)
Deva-16 (x 16)
0.1 to 100.0 ms
10 to 1000 ms
–20.0 to 0.0 dB
4.0:1 to 20.0:1
0.0 to 6.0 dB
(A x 8, D x 8)
Off or 30 to 240 Hz
(A x 8, D x 8)
0 to 60 ms
(A x 8, D x 8)
Yes, No
(x 8)
0.1 to 100.0 ms
10 to 1000 ms
–20.0 to 0.0 dB
4.0:1 to 20.0:1
0.0 to 6.0 dB
10
16
24
16 / 24
44.1, 47.952, 48, 48.048, 88.2, 96, 96.096, 192*
