Chapter 3_______________________________________________________Zaxcom Deva User's Manual

Main Menu page

Page purpose:
How to get here:
(MENU key)

(Mode Status button)

Page Notes

None

Page Level Shortcuts

None
Mode Status button
(Figure 3-3 displays STOP)
This button appears on ALL remaining pages.
Located at the top right corner of EVERY page (except on the
operating mode (RECORD,
Pressing this button (or the MENU key on the front panel) takes you back one level.
NOTE: Pressing the Mode Status button does not change the Deva's operating mode. It only brings you back
one page or level within a page.

Disk Mix button

Pressing it displays the

Output Mix button

Pressing it displays the

Faders button

Pressing it displays the

Time Code button

Pressing it displays the

Setup button

Pressing it displays the

Input Configure button

Pressing it displays the
This page provides access to all of Deva's operating functions and parameter adjustments.
PLAY or STOP).
Disk Mix page {p.42}.
Output Mix page {p.47}.
Faders page {p.54}.
Timecode page {p.57}.
Setup page {p.60}.
Input Configure page (Analog Inputs selected)

Figure 3-3 Main Menu page

Home page
40
{p.35}), it displays the current
{p.87}.
