Chapter 3_______________________________________________________Zaxcom Deva User's Manual

HPF button

Press it to enter a value for the cutoff frequency for this input's high-pass filter.
Off
(Valid range: 30 – 240 Hz, Value step: 1)
HPF button Shortcuts
See: Common Data Entry Field Shortcuts List
Limiter (On / Off) button
Pressing it toggles the limiter for this channel
Trimmer graphic fader
Adjusting it sets the pre-amp level for this channel to optimize this channel's performance. If you look at the
bottom of the fader background, you'll see the numeric representation of the slider's position, within 0.25 dB.
This makes it easy to repeat a setting, if necessary. (Valid range: -20 – 0 – +30 dB, Value step: 0.25)
NOTE: The scale is NOT dBFS and it is NOT dBu. It is a purely relative comparison to the input value arriving
at the fader.
Level meter
It displays the current audio level for this channel. The view point for this meter is post trimmer and pre-fader.
The scale is dBFS.
Digital Output button
Pressing it enables (On) / disables (Off) the digital output for this channel.
Dynamics button
Pressing it displays the
EQ button
Pressing it displays the
NOTE: Unlike the Fusion-10, the Effects Package is included in both the Deva-5.8 and Deva-16.
BUS button
Pressing it displays the
Mix12 Input Trim Select button
Normal
Tx ZaxNet – Indicates any changes made to this channel's Mix-12 Input Trim knob will send a ZaxNet
Analog Input (#) – Dynamics page
Analog Input (#) – EQ page
Analog Input (#) – BUS page
– Indicates any changes made to this channel's Mix-12 Input Trim knob will adjust the Deva's
preamp for this channel.
command to adjust this channel's transmitter preamp.
{p.159}
On or Off. This limiter's settings cannot be adjusted.
{p.91}.
{p.94}.
{p.97}.
90
