Zaxcom Deva User's Manual_______________________________________________________ Chapter 3

Preset button

Pressing it allows you to save and recall up to five saved settings. Think of each preset as a page on which to write
the configuration.
To save a configuration, perform the following:
1) Move to the Preset # you want to build. Normally, the first to be built would be Preset 1.
2) If you have not previously saved anything into the preset, it will be a blank slate. Establish all of the required
items for this preset.
3) If you need to establish any additional presets, repeat steps 1 & 2 for each additional configuration.
To load a configuration once it has been saved, simply press the Preset button until the number displayed is the
one you're expecting. At that point, examine the configuration; it will be as you had saved it. If, at any time, you
need to update the configuration, inset your changes, they are automatically saved.
NOTE: The Limit column settings are not saved in a specific preset #.

(Analog / Digital) In Toggle button

Press it to select either analog or digital inputs. Selecting the button once changes it, selecting it again changes it
back.

(Pre- / Post-) Fader button

Pressing it allows you to choose whether each selection is pre- or post-fader. For example, you can record the
microphone on one channel of the Deva post-fader and on another pre-fader, so it is unaffected by the mix.
Pre-Fader: "A" or "D" –
Post-Fader: "A" or "D" – Black letter.

-MORE- button

Pressing it cycles the buttons displayed on the bottom of the page.

Clear All button

Pressing it removes all selections from the matrix and empties the contents of the current preset.
NOTE: The Limit column settings are not cleared when this button is pressed.

Phase Invert button

Pressing it reverses the phase of the selected input. A reversed phase input appears with a bar over the letter (A
or D).

Limiter Settings button

Pressing it displays the
White letter.
Disk Limiter Settings page
43
{p.45}.
