Chapter 3_______________________________________________________Zaxcom Deva User's Manual

Delay Mode button

Pressing it toggles between msec and samples.
NOTE: It is not possible to have the channels' delay values in different units (msec and samples). If you enter a
value on one of the buttons and change the unit, the previously entered value(s) will be rounded (up or down)
to fit the new unit. So, pick one of the units and stick with it!

Adjusting the Delay

1. Press one of the Channel (#) buttons for the channel you want to adjust.
The button changes to
2. Press either the More Delay button, Less Delay button or Enter Delay button.
3. Repeat steps 1 & 2 until all channels have been adjusted.
NOTE: When using radio microphones, which have an inherent 0 to 8 ms delay, you can minimize phasing
anomalies between digital and analog equipment by adding the appropriate delay to the analog inputs.
White indicating it is the selected channel.
110
