Zaxcom Deva User's Manual_______________________________________________________ Chapter 3

S: T: N: button

(Figure 3-2
Displays the user entered metadata (Scene, Take, Note) for the current Take (during playback or metadata
review) or the NEXT Take to be recorded.
Pressing it displays the
Input (#) meters & buttons
(Figure 3-2
Up to sixteen* tracks can be displayed. Unarmed tracks are displayed with a line through them. Individual tracks
can be shown or hidden using the Number of Home Screen Meters button on the
The meters use PPM / Peak Hold ballistics. The Peak Hold Bar remains for 5 seconds. The color of the audio
level bar changes from Green to Yellow when the level reaches -20 dBFS or above, and changes to Red when it
reaches -10 dBFS or above. The channel number on the far right changes from Green to Yellow when the Peak
Hold Bar reaches -20 dBFS or above, and changes to Red when it reaches -10 dBFS or above.
* Deva-5.8 – maximum 10 tracks, Deva-16 – maximum 16 tracks

Solo Mode

You can solo any input channel by touching the meter display for the desired track for 2 seconds. The display will
enter 'solo' mode ("SOLO" and the number of the solo'd track is displayed in the Headphone button). Then,
touching any other track instantly solos the new track.
To exit 'SOLO' mode:
touch the Headphone button, or
touch any track for 2 seconds, or
exit the page.

Arm / Disarm a Recording Track

Pressing the SHIFT key on Deva's front panel while pressing the appropriate meter on the Home page, arms /
disarms the recording of that channel. Disarmed tracks are indicated by a line drawn through the track's meter.
{p.35} displays on the first line
Scene Take Note page
{p.35} displays on the right half of the page)
S:1 T:1)
{p.131}.
39
Meter Menu page {p.67}.
