Zaxcom Deva User's Manual_______________________________________________________ Chapter 3

Decay button Shortcuts

Clicking the button the first time selects it. This allows the value to be modified by the Inc button or Dec button.
Clicking it a second time opens it for direct access.
See: Common Data Entry Field Shortcuts List

Thresh button

(Compressor Threshold) It sets the threshold above which gain reduction occurs according to the Compressor
Ratio setting. (Valid range: -60.0 – -20.0 – 0.0 dB, Value step: 0.1)

Thresh button Shortcuts

Clicking the button the first time selects it. This allows the value to be modified by the Inc button or Dec button.
Clicking it a second time opens it for direct access.
See: Common Data Entry Field Shortcuts List
BACKSPACE key – 1) The first time the backspace is pressed it enters a decimal point.

Ratio button

(Compressor Ratio) It sets the compressor ratio, i.e. 4.0:1 means for every 1 dB above the Compressor
Threshold the gain will be reduced 4 dB. (Valid range: 1.0:1 – 20.0:1, Value step: 0.1)

Ratio button Shortcuts

Clicking the button the first time selects it. This allows the value to be modified by the Inc button or Dec button.
Clicking it a second time opens it for direct access.
See: Common Data Entry Field Shortcuts List

Gain button

(Make up Gain Setting) It is used to compensate for the gain reduction caused by the action of the compressor.
(Valid range: 0.0 – 20.0 dB, Value step: 0.1)

Gain button Shortcuts

Clicking the button the first time selects it. This allows the value to be modified by the Inc button or Dec button.
Clicking it a second time opens it for direct access.
See: Common Data Entry Field Shortcuts List
BACKSPACE key – 1) The first time the backspace is pressed it enters a decimal point.

Copy Compress button

It is used to save you time and copy all compressor values to the current channel from another specified channel.
To copy the settings from one compressor to another, perform the following:
1. Go to the channel you want to copy the settings to.
2. Press the Copy Compress button. (A data entry field is displayed.)
3. Using the keypad, enter the channel that you want to copy the compression settings from and press the ENTER
key. (The settings are copied and the page is updated.)
4. Repeat 1 – 3 for each additional channel you want to copy settings to.

Inc button

Pressing it increments the selected parameter by its step value.

Dec button

Pressing it decrements the selected parameter by its step value.
2) If the cursor is on the last character, it deletes the character at the cursor and moves
the cursor left one character.
3) If the cursor is not on the first or last character, it moves the cursor left one position,
without deleting the character.
4) If the cursor is on the first character, it has no effect.
2) If the cursor is on the last character, it deletes the character at the cursor and moves
the cursor left one character.
3) If the cursor is not on the first or last character, it moves the cursor left one position,
without deleting the character.
4) If the cursor is on the first character, it has no effect.
103
{p.159}
{p.159}, with the following exception(s):
{p.159}
{p.159}, with the following exception(s):
