Zaxcom Fusion User's Manual______________________________________________________Chapter 2

Mic/Line Level button

To set the Mic/Line input gain, press the Mic/Line Level button, then select the individual Input Channels. MIC
appears in

Clear All button

This button provides a convenient way to clear all the settings, and resets this page back to the factory default
settings.

Adjust Delay button

Pressing it takes you to the

High Pass Hz button

To set the Highpass Frequency, do the following:
1. Press the High Pass Hz button
You are prompted to enter the highpass frequency in Hz.
2. Use the numeric keys to enter the frequency.
The valid range is 30 to 240 Hz. Default setting: 70 Hz
Any value outside this range is placed near the closest valid number within this range.
3. Press High Pass Hz button or the ENTER key to finish entering the Cutoff Frequency.

High Pass (#) Hz button Shortcuts

See: Common Data Entry Field Shortcuts List

Adjust Trim button

Pressing it takes you to the
DARK BLUE. LINE appears in BLACK.
Analog/Digital Input Delay page
Analog/Digital Input Trim page
{p.101}.
{p.146}
{p.103}.
81
