Bosch AMAX panel 4000 Installation Manual

Icp-amax4-p1 / icp-amax4-p2-en / icp-amax-p3-en.
Hide thumbs

Advertisement

AMAX panel 4000 / AMAX panel 4000 EN
ICP-AMAX4-P1 / ICP-AMAX4-P2-EN / ICP-AMAX-P3-EN
en
Installation Guide

Advertisement

   Summary of Contents for Bosch AMAX panel 4000

  • Page 1

    AMAX panel 4000 / AMAX panel 4000 EN ICP-AMAX4-P1 / ICP-AMAX4-P2-EN / ICP-AMAX-P3-EN Installation Guide...

  • Page 3: Table Of Contents

    AMAX panel 4000 / AMAX panel 4000 Table of Contents | en Table of contents Graphics Safety Short Information System overview Communication Zones Tamper Description Area User Programmable Output Key Switch Event Log Keypads Optional Modules and Peripheral Devices Keypad 5.1.1...

  • Page 4

    AMAX panel 4000 / AMAX panel 4000 en | Table of Contents 5.6.3 Address Setting 5.6.4 Wiring 5.6.5 Status Indicator RFRC-OPT Radion Receiver Remote Programming Software Programming Key / Firmware Upgrade Key Installation Module Installation Battery Installation System Power Up...

  • Page 5

    AMAX panel 4000 / AMAX panel 4000 Table of Contents | en 7.5.10 Internal Siren Beep As Indication 7.5.11 Battery Check Interval 7.5.12 Cross Zone Timer 7.5.13 AC Power Supply Fault Report Delay 7.5.14 Date and Time 7.5.15 Fault Inquiry 7.5.16...

  • Page 6

    AMAX panel 4000 / AMAX panel 4000 en | Table of Contents 10.7 Bypassing 10.7.1 Bypassing Zones 10.8 Codes 10.8.1 Add/Change and Delete User Code 10.8.2 Change Individual Code 10.9 Keypad Alarm Operation Commands 10.9.1 Keypad Panic Alarm 10.9.2 Keypad Fire Alarm 10.9.3...

  • Page 7: Graphics

    AMAX panel 4000 / AMAX panel 4000 Graphics | en Graphics Risk of shock if N,L1 or is connected incorrectly. For operation safety, the ground terminals must AUX 1: < 900mA be connected. AUX 2: < 900mA AUX1 AUX2 AUX2...

  • Page 8: Safety

    Notice! The system must be installed and maintained by qualified installer / service person. Bosch recommends testing the whole alarm system at least once a week. Maintenance should be done by qualified installer / service person four times a year.

  • Page 9: Short Information

    Each control panel can be tailored to meet your requirements quickly and easily. The programming simplicity makes your installation quick, accurate and rewarding. The AMAX panel 4000 equipped with 16 on-board wired zones can be expanded to 64 wired zones.

  • Page 10: System Overview

    Key Switches are connected to onboard or extension module zone inputs. Event Log AMAX panel 4000 stores events in its non volatile memory. Even if the alarm control panel does not transmit related event report, the event will be maintained. The events in history can be directly inquired through the keypad or uploaded to the remote programming software.

  • Page 11: Optional Modules And Peripheral Devices

    AMAX panel 4000 / AMAX panel 4000 Optional Modules and Peripheral Devices | en Optional Modules and Peripheral Devices Keypad 5.1.1 Brief Introduction The system supports up to 16 keypads. Five supported keypads are as follows: – IUI-AMAX4-TEXT (LCD Text Keypad) –...

  • Page 12: Wiring And Installation

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Table 5.1: Keypad Address Settings IUI-AMAX-LED8 and IUI-AMAX-LCD8 keypads can only be set to address 1 or address 2 through the address jumper. – Jumper not short-circuited: Address 1.

  • Page 13: Test

    The alarm control panel can connect to up to 16 keypads at the same time, upto 8 wired to Bosch Option Bus 1 and upto 8 wired to Bosch Option Bus 2. The total length of the cable for connection of all keypads and expansion module wired to one Bosch Option Bus cannot exceed 700m.

  • Page 14

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Alarm Control Panel DX2010 Yellow Green Black (-) Red (+) Figure 5.3: Connecting DX2010 to the Control Panel For use of external power supply, refer to Figure below.

  • Page 15: Tamper

    AMAX panel 4000 / AMAX panel 4000 Optional Modules and Peripheral Devices | en 5.2.3 Tamper Each DX2010 module has an onboard tamper and one tamper input, not belonging to zone inputs. When the tamper event of DX2010 module occurs, the tamper report is sent with the module address.

  • Page 16: Status Indicator

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Example : Data Bus Location 103 - DIP Settings Figure 5.5: DX2010 DIP Switch Settings 5.2.5 Status Indicator – Flashing once per second: Indicating normal operation.

  • Page 17: Dx3010 Output Expansion Module

    The alarm control panel supports up to two DX3010 output expansion modules. The module is connected to Bosch option bus1 or 2. Each module supports eight fully programmable relay outputs. Like on-board output, DX3010 can be programmed as the output following the area such as alarm event, arming / disarming status event and zone alarm event.

  • Page 18: Address Setting

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Alarm Control Panel DX3010 Yellow Green Black (-) Red (+) External Power Supply Figure 5.8: Connecting DX3010 to the Control Panel with External Power Supply Notice! When the external power supply is used, the black wire (-) is not allowed to be grounded.

  • Page 19: Test

    For more information about installation, see B426 Installation and Operating Guide. Also refer to , page 28 for more details. 5.4.3 Wiring Connect B426 to Bosch option Bus 1 or 2. The cable may not exceed 150 meters. Bosch Sicherheitsysteme GmbH Installation Guide 2013.07 | 03 | F.01U.267.112...

  • Page 20: Address Setting

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Alarm Control Panel B426 Yellow Green Black Figure 5.10: Connecting B426 to the Control Panel 5.4.4 Address Setting Turn the rotary switch to 6, i.e., set the address to 134 when the first B426 is used. Turn the rotary switch to 9, i.e., set the address to 250 when the second B426 is used.

  • Page 21: Test

    AMAX panel 4000 / AMAX panel 4000 Optional Modules and Peripheral Devices | en For more information about indicators, see B426 Installation and Operating Guide. 5.4.7 Test The alarm control panel tests the communication normally with the module. In case of communication failure, a fault report with the module address is sent.

  • Page 22: Test

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Alarm Control Panel Figure 5.11: GPRS Mode in Support of IP Alarm Control Panel Figure 5.12: GSM Mode in Support of PSTN (Contact ID) For the status indicator, configuration and more information about ITS-DX4020-G, see Installation and Operation Guide.

  • Page 23: Rf 3227e Rf Receiver

    Optional Modules and Peripheral Devices | en RF 3227E RF Receiver 5.6.1 Brief Introduction The RF3227E RF Receiver allows the use of wireless devices using AMAX panel 4000. 5.6.2 Installation Considerations The receiver should be mounted in a central location in regard to all wireless sensors, whenever possible.

  • Page 24

    AMAX panel 4000 / AMAX panel 4000 en | Optional Modules and Peripheral Devices Wall Tamper Jumper ADDR Wall Tamper disabled Wall Tamper enabled (Default position Jumper left on pin for storage only. Figure 5.15: Wall Tamper Jumper – Replace the inner cover.

  • Page 25

    AMAX panel 4000 / AMAX panel 4000 Optional Modules and Peripheral Devices | en Mounting Holes Antenna Connectors ADDR Bus and Power Cover Tamper Connector Switch Figure 5.17: Mounting the Receiver ADDR Figure 5.18: Bus and Power Connector Use one of these...

  • Page 26: Address Setting

    5.6.4 Wiring Connect RF3227E receiver to Bosch option Bus 1 or 2. The cable may not exceed 300 m. Adding additional devices to the bus might reduce the maximum distance. Shielded cable is not required. Do not use twisted pair wire.

  • Page 27: Status Indicator

    The receiver failed power-up self tests. Replace the one minute receiver RFRC-OPT Radion Receiver General Information The RFRC Opt Radion Receiver allows the use of wireless devices using AMAX panel 4000. Installation Address Setting AMAX 4000 panel supports one receiver only. Wiring Connect RFRC - OPT Radion Receiver to Bosch opton Bus 1 or 2.

  • Page 28: Installation

    | Installation Installation This chapter specifies installation and system power up of the AMAX panel 4000. This system / product must be installed by a qualified installer / service person. During installation and wiring, the control panel power source must be switched-off to prevent equipment damage.

  • Page 29: Battery Installation

    AMAX panel 4000 / AMAX panel 4000 Installation | en E N √ E N √ Enclosure - Standard Enclosure with mounting plate 6.2 Enclosure with mounting plate Figure 6.1: Enclosure / with mounting plate Expansion modules can be placed in enclosure of the alarm control panel. Several places are available.

  • Page 30: System Power Up

    AMAX panel 4000 / AMAX panel 4000 en | Installation Danger! Special care is required in connecting the positive (red) wire and the “BATT +” port of the alarm control panel. If short-circuiting with the “BATT +” port of the alarm control panel or the enclosure, electric arc will occur.

  • Page 31: System Status Indicator

    AMAX panel 4000 / AMAX panel 4000 Installation | en System Status Indicator The system status is indicated by the LED status indicator on the system main board. Slow flash of red status indicator (repeating on and off with an interval of 1 second) indicates normal system operation.

  • Page 32: Settings

    This chapter specifies the properties and the behavior of the AMAX panel 4000. Communication and Reporting This section outlines the programming information required for the AMAX panel 4000 / AMAX panel 4000 EN when communicating with a base station receiver. These parameters specify the telephone numbers/IP address to be called, transmission formats and internet communication options.

  • Page 33: Receiver Subscriber Id Number

    Contact ID. Transmission Formats (Contact ID, SIA, Conettix IP) The AMAX panel 4000 / AMAX panel 4000 EN provides three kinds of transmission formats, Contact ID, SIA and Conettix IP format for its dialing and communication features. Program the transmission format for Receiver 1, 2, 3 and 4 separately in Address 023, Address 053, Address 083 and Address 113 (refer to Transmission Format).

  • Page 34

    AMAX panel 4000 supports SIA Format. SIA allows transmitting System ID, event code, zone ID, area ID, event time and also event text. Conettix IP Format AMAX panel 4000 supports Conettix IP. AMAX panel 4000 with DX4020G and B426 are able to connect to Bosch Receivers 6600/6100 using Conettix IP Format. Event Description...

  • Page 35

    AMAX panel 4000 / AMAX panel 4000 Settings | en Event Description Dialer Event Recall Event Event ARM AWAY 3401 √ √ √ DISARM AWAY 1401 √ √ √ ARM STAY 3441 √ √ √ DISARM STAY 1441 √ √...

  • Page 36

    AMAX panel 4000 / AMAX panel 4000 en | Settings Event Description Dialer Event Recall Event Event FIRE 24 HOUR RESTORE 3110 √ OUTPUT FAULT 1320 √ √ OUTPUT RESTORE 3320 √ DAYLIGHT SAVING TIME +1h 1625 √ √ DAYLIGHT SAVING TIME -1h 1625 √...

  • Page 37: Receiver Network Programming Options

    AMAX panel 4000 / AMAX panel 4000 Settings | en Event Description Dialer Event Recall Event Event RF RECEIVER JAM 1344 √ RF RECEIVER JAM RESTORE 3344 √ RF RECEIVER CONFIGURATION CONFILICT √ RF RECEIVER CONFIGURATION CONFILICT √ RESTORE RF POINT MISSING 1381 √...

  • Page 38: Dual Ip

    AMAX panel 4000 / AMAX panel 4000 en | Settings When no callback from the receiver after the acknowledge time is reached, the control panel takes it as an unsuccessful communication and makes another attempt. The time ranges from 5 to 99 sec.

  • Page 39: System Reporting

    AMAX panel 4000 / AMAX panel 4000 Settings | en 7.1.6 System Reporting Report Transmission Sequence If the event has disabled the report (option 0), no report is sent out. The domestic alarm is set as configured. If the report has any destination to contact the panel (option 1, 2, 3, 4, 5, 6, 7), It will call the related destination by related reporting format type and subscriber ID Number.

  • Page 40

    AMAX panel 4000 / AMAX panel 4000 en | Settings – If the event reporting path is set to sending report to receiver 1, receiver 2 as backup; sending report to receiver 3, receiver 4 as backup; the alarm control panel will send reports to corresponding paths.

  • Page 41

    AMAX panel 4000 / AMAX panel 4000 Settings | en – When communication path 1 fault recovers, zone indicator 1 goes off, indicating that the communication path 1 fault of the zone status recovery report recovers and the communication part 1 fault of the keypad emergency report recovers.

  • Page 42

    AMAX panel 4000 / AMAX panel 4000 en | Settings Zone Tamper Alarm In case of zone tamper event, the tamper report will be sent. When zone tamper recovers, the system status report will be sent. Arming/Disarming Reporting (System) The system disarming report is sent at the disarming command and the system arming report is sent when the arming succeeds.

  • Page 43

    AMAX panel 4000 / AMAX panel 4000 Settings | en Auxiliary Power Fault Report When the system detects auxiliary power fault, the report will be sent. Auxiliary Power Fault Restore Report When the system detects auxiliary power fault recovery, the report will be sent.

  • Page 44: Automatic Test Report

    Remote Programming Software, i.e. RPS, includes Bosch A-Link Plus software and the third- party software of integrated with Bosch SDK. The IP remote connection function allows to establish a connection from the remote PC to the alarm control panel through LAN or WAN to perform remote programming and control.

  • Page 45: Domestic Call

    AMAX panel 4000 / AMAX panel 4000 Settings | en When RPS is opened, a connection can only be established when the IP address and port number of the alarm control panel have not changed, after RPS received previous data..

  • Page 46: Zones

    7.2.1 Zone Inputs On-board Inputs: There are 8 onboard hard-wired inputs for AMAX panel 4000 / AMAX panel 4000 EN. An additional input is provided for enclosure tamper but does not subtract from the 8 onboard totals. On-board Zone Response Time: Each on-board zone response time is: Zone Status trigger time >= 400ms, must response...

  • Page 47: Zone Function Settings / Zone Types

    AMAX panel 4000 / AMAX panel 4000 Settings | en Loop resistance (ohm) Zone Status Type 1430 tamper 1650 2200 2750 normal 2970 4400 4950 triggered 5220 ∞ tamper Using one 2.2K resistor as EOL of the tamper zone, which works together with the zone EOL 2.2K.

  • Page 48

    AMAX panel 4000 / AMAX panel 4000 en | Settings Follower Interior Follower 24-Hour Key-Switch Toggle Key Switch on/off 24 Hour Panic 24 Hour Fire 24 Hour Fire With Verification Tamper Bolt Contact External Fault Delay Exit Interior Delay Exit...

  • Page 49

    AMAX panel 4000 / AMAX panel 4000 Settings | en 2 - Interior Instant The interior instant zone will perform as below: Disarm: – same as the Instant Zone disarm status AWAY Arm: – same as the Instant Zone AWAY Arm status STAY Arm: –...

  • Page 50

    AMAX panel 4000 / AMAX panel 4000 en | Settings – If there are two or more zones programmed as delay zones and both are triggered, the follower zone will follow the first triggered delay zone STAY ARM: same as the delay zone.

  • Page 51

    AMAX panel 4000 / AMAX panel 4000 Settings | en – A Fire zone does not send a restore report until the zone is restored. 10 - External Fault Zone The Fault Zone/Input will perform as below: Disarm: – Zone normal - no Alarm / no report –...

  • Page 52

    AMAX panel 4000 / AMAX panel 4000 en | Settings Zone normal: Activate Disarm Wiring Diagram for Key-switch Zone: short for arm. The momentary time is capable of lasting Min. 300ms. Zone Wiring Diagram for Key-switch Zone: short for arm. The momentary time is capable of lasting Min.

  • Page 53: Zone Function Settings / Zone Options

    AMAX panel 4000 / AMAX panel 4000 Settings | en – Refer to Section Keypad Indicators, page 20 to see how the zone is displayed during exit time. 18 - Technical Alarm The Technical Alarm zone will perform as below: Disarm: –...

  • Page 54

    AMAX panel 4000 / AMAX panel 4000 en | Settings Chime Mode Zone Pulse count Disabled 1-9 Pulses Zone Lockout Disabled 1 Times Alarm Lockout 3 Times Alarm Lockout 6 Times Alarm Lockout Alarm Duration Zone Tamper Disabled Enabled Zone Status Report...

  • Page 55

    AMAX panel 4000 / AMAX panel 4000 Settings | en Zone Bypass If this option is enabled, the operator can bypass zones before arming the system. If this option is disabled, manual bypass of the zone will not be available. After manual bypass of the zone, a zone bypass report will be sent.

  • Page 56

    AMAX panel 4000 / AMAX panel 4000 en | Settings Locking within the period of alarm output time. Repeating the process of alarm locking in the period of alarm output time, without limit to times. Zone Tamper The system supports the tamper detection of the zone. This function ensures that the zone is in normal operating status.

  • Page 57: Adding And Changing Zone

    AMAX panel 4000 / AMAX panel 4000 Settings | en – When no more zones (with cross zone option) are triggered within the cross zone time, no alarm is created. – When the first zone is triggered twice or more within the cross zone time, no alarm is created.

  • Page 58: Outputs

    AMAX panel 4000 / AMAX panel 4000 en | Settings In a multi area system the following table shows area assignment and keypad indication of zones: Zone Number Area Indication keypad area 1 Indication keypad area 2 Outputs 7.3.1 Onboard / Extension Output...

  • Page 59

    AMAX panel 4000 / AMAX panel 4000 Settings | en 2 - System Armed 0=all areas, 1-16 = Areas1-16 The output operates on below conditions: System armed after system reset System operated the arm command and until system is armed. (When system is operating the arm command, the system will arm after the exit delay time is up.)

  • Page 60

    AMAX panel 4000 / AMAX panel 4000 en | Settings System is STAY armed +zone intruder alarm (intruder alarm = instant / interior instant / delay / interior delay / delay exit / interior delay exit / follower / interior follower / 24h (can be...

  • Page 61

    AMAX panel 4000 / AMAX panel 4000 Settings | en 11 - AC Power Supply Fault This output operates when a AC MAINS fault occurs. The output is reset: When the AC power supply is restored and fault is reset.

  • Page 62

    AMAX panel 4000 / AMAX panel 4000 en | Settings lf this duration is programmed as 000, the output will continue till the System is Disarmed. 19 - STAY Armed This output operates when System is STAY Armed. The output is reset: When the output programmed duration is up.

  • Page 63: Output Options

    AMAX panel 4000 / AMAX panel 4000 Settings | en 7.3.3 Output Options The Value Ranges of Output Programming Options Output Event Type Description Output Area / Zone Output Not Used Event System Disarmed 0 = All Areas 1 – 16 = Areas 1 - 16...

  • Page 64: Alarm Siren Ringing Time

    AMAX panel 4000 / AMAX panel 4000 en | Settings Walktest Output Continuous output Mode Pulse Inverted Output 000 - 0 - 999 seconds Time *1 Output Timer is fix. (1 sec) Output Mode Two different polarities are available. 0 - Continuous output This polarity is a stable low-level output.

  • Page 65: System Settings - General

    AMAX panel 4000 / AMAX panel 4000 Settings | en Keypad User Codes #1 to #64 (reported 1 to 64) Key Fob User Codes *1 to *128 (reported 65 to 192) User Codes for special purpose: Use User Code 254 to send report when arming/disarming the system by key-switch user.

  • Page 66: Event Record Count Per Set/unset Period

    AMAX panel 4000 / AMAX panel 4000 en | Settings 7.5.8 Event Record Count per Set/Unset Period Option Event Record Count per Set/Unset Period defines the maximum number of records for an event within the set/unset period. 7.5.9 System Tamper Indication In Area Option System Tamper Indication In Area configures system where system tamper event is indicated.

  • Page 67

    1 - 2 Panel Aux Power 1 - 2 Fault Bosch Option Bus Power Failure 1 - 2 Bosch Option Bus 1 - 2 Power Fault RF Repeater AC Power Failure 1 - 8 RF Repeater 1-8 AC Power Fault...

  • Page 68

    AMAX panel 4000 / AMAX panel 4000 en | Settings Output Failure Onboard Output Failure 1 Onboard Output 1 Fault 2 Onboard Output 2 Fault Keypad Failure 1 - 16 Keypad 1 – 16 Fault System Failure Date Time not set...

  • Page 69

    AMAX panel 4000 / AMAX panel 4000 Settings | en – Network / IP Module 1 Failure Condition: No communication with the DX4020/ITS-DX4020G if DX4020/ITS-DX4020G is programmed. Restore: Communication with DX4020/ITS-DX4020G is normal and fault is reset. Supervise: Report the DX4020/ITS-DX4020G fault to configured destination on address 124 when the fault is detected.

  • Page 70

    AMAX panel 4000 / AMAX panel 4000 en | Settings When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. Printer Missing Condition: No communication with printer if printer is enabled and the DX4010 is normal.

  • Page 71

    AMAX panel 4000 / AMAX panel 4000 Settings | en When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. RF Receiver 1 Jammed Condition: Much disturb signal around the receiver if wireless module is enable.

  • Page 72

    AMAX panel 4000 / AMAX panel 4000 en | Settings 3. When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. – RF Config Failure...

  • Page 73

    Voltage is raised to 12V and fault is reset. Supervise: Monitor the voltage by MPU. Report the Bosch Option Bus Power Supply fault to the configured destination programmed on address 124. Slow flash FAULT indicator (refer to the detailed description in chapter keypad indicators) When the fault is reset, send the restored report to the configured destinations.

  • Page 74

    AMAX panel 4000 / AMAX panel 4000 en | Settings – RF Keyfob Battery Failure No description defined 3 -Output Failure – Onboard Output Failure On-board output 1 to 2 fault The on-board output 1 to 2 is detected as short circuit, open circuit or over current status, the on-board output 1 to 2 fault will occur.

  • Page 75

    AMAX panel 4000 / AMAX panel 4000 Settings | en No report to the control panel system when date and time setting is recorded in nonvolatile memory and Control Panel is reset. The FAULT indicator is turned off when there is no other system fault.

  • Page 76

    AMAX panel 4000 / AMAX panel 4000 en | Settings Recovery conditions: When the module tamper recovers, tamper 1, 2, 3, 4, 5 or 6 will be recovered. Fault monitoring: When the DX2010 module 1, 2, 3, 4, 5 or 6 tamper is detected, the report will be sent to the relevant path according to programming address 0124.

  • Page 77: Quick Arming

    AMAX panel 4000 / AMAX panel 4000 Settings | en 8 - External Failure Condition: Fault contact (direct connected to the Zone) is triggered (Zone type = External Fault) Restore: Fault contact is restored and Fault condition is reset. Supervise: Report the Fault condition to configured destination on Address 124 when the Fault condition is detected.

  • Page 78: Zone Tamper Bypass When Deol Zone Is Bypassed

    AMAX panel 4000 / AMAX panel 4000 en | Settings AC Fault Report Settings In case of AC power fault, the fault report will be delayed for 1 hour or 10 minutes, or transmitted along with other reports. The AC power fault event will be displayed on the keypad 1 hour or 10 minutes later.

  • Page 79: Area Delay

    AMAX panel 4000 / AMAX panel 4000 Settings | en – If any zones under common zones are in triggered or tamper status and the forced arming is disabled, the common area cannot be armed. For programming of common area, see Common Area Settings.

  • Page 80: Configuration

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Configuration This chapter specifies how to configure of the AMAX panel 4000. It includes the different ways to program the AMAX panel 4000. System Power Up After the system is powered up, set date and time. Otherwise, the system prompts as fault.

  • Page 81: Bosch Sicherheitsysteme Gmbh

    AMAX panel 4000 / AMAX panel 4000 Configuration | en User Code Commands (Default User Code = 2580 Default Inst. Code = 1234) Command Function S w itch to M a in K e yp a d [C o d e ] + [0 ][0 ][0 ] + [# ] (T e xt K P ) √...

  • Page 82: Reset To Factory Default Settings

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Reset to Factory Default Settings The factory Default can be reset with the ‘Resetting to Factory Default’ pads on the main board of the control panel. Disconnect the AC power supply and backup battery to the control panel.

  • Page 83

    AMAX panel 4000 / AMAX panel 4000 Configuration | en INSTALLER MENU COM+REPORT SETTING RECEIVER SETTING REPORT SETTING TEST REPORT DURAT. DUAL IP REMOTE ACCESS RPC IP/PORT/DHCP DOMESTIC/CALLBACK RING TIMES CODE SETTING USER CODE INSTALLER CODE CODE LENGTH CODE PERMISSIONS...

  • Page 84

    AMAX panel 4000 / AMAX panel 4000 en | Configuration COM+REPORT SETTING RECEIVER SETTING INPUT RECEIVER No PHONE/IP PORT No SUBSCRIBER ID No FORMAT NETWORK ANTIREPLAY ACK WAIT TIME: sec NETW. POLLING: min REPORT SETTING ZN RESTORE REPORT AWAY REPORT...

  • Page 85

    AMAX panel 4000 / AMAX panel 4000 Configuration | en CODE SETTING USER CODE INPUT USER No USER CODE PRIORITY USER CODE IN AREA CHANGE USER CODE INSTALLER CODE CHANGE INST. CODE CODE LENGTH CODE LENGTH CODE PERMISSIONS TAMPER RESET USER ARM/DISARM INSTAL.

  • Page 86

    AMAX panel 4000 / AMAX panel 4000 en | Configuration KP/AREA SETTING KEYPAD AREA INPUT KEYPAD No KEYPAD IN AREA AREA TIMING INPUT AREA No EXIT DELAY: sec ENTRY DELAY: sec COMMON AREA COMMON AREA KP TONE/LOCKOUT KEYPAD ALARM TONE KEYPAD LOCK COUNT Figure 8.6: KP Area Setting...

  • Page 87

    AMAX panel 4000 / AMAX panel 4000 Configuration | en SYSTEM SETTING FUNCTION SETTING DATE/TIME CHANGE DATE/TIME FAULT CONFIG KEYPAD FAULT SOUND AC FAULT REP. TIME DISABLE FAULT REPO BATT. CHK INTERVAL PHO. LN SUPERVISED SIREN SUPERVISED QUICK ARM ONLY */#...

  • Page 88

    AMAX panel 4000 / AMAX panel 4000 en | Configuration OUTPUT SETTING OUTPUT SETTINGS ENTER OUTPUT No OUTPUT EVENT TYPE OUTPUT AREA / ZONE OUTPUT MODE OUTPUT TIME: sec SIREN SETTINGS SIREN TIME: min SIREN BEEP ENABLE IN SIREN IND. EN SIREN OFF ON KEY Figure 8.8: Output setting...

  • Page 89

    AMAX panel 4000 / AMAX panel 4000 Configuration | en RF SETTING RF PARA. SETTING RF RECEIVER RF RECEIVER ENABLE RF SUPERVISION RF DEVICE SUPERV: RF JAM DETECT LEV. SIGNAL JAM DETECT: RF LOW BATT REPEAT LOW BATT. REPEAT: SIREN BEEP AR/DIS...

  • Page 90: Led/lcd Keypad Programming

    AMAX panel 4000 / AMAX panel 4000 en | Configuration 8.5.2 LED/LCD Keypad Programming Enable LED keypad or Icon LCD keypad and make sure that the system is in disarmed status. Enter programming mode: Enter the Installer Code (the default is 1234) + [958] and press [#].

  • Page 91: Pc Programming

    – Make sure that the value for parameter “Installer code” is the same as currently programmed in AMAX panel 4000. The value is 1234, when firmware of AMAX panel 4000 was upgraded or AMAX panel 4000 has factory settings. Bosch Sicherheitsysteme GmbH Installation Guide 2013.07 | 03 | F.01U.267.112...

  • Page 92

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Figure 8.11: Control panel configuration- Destination 2013.07 | 03 | F.01U.267.112 Installation Guide Bosch Sicherheitsysteme GmbH...

  • Page 93: Direct Connection

    AMAX panel 4000 / AMAX panel 4000 Configuration | en Figure 8.12: Control panel configuration - System options 8.6.1 Direct Connection The direct connection function allows establishing a connection from the remote PC to AMAX panel 4000 via USB to perform remote programming and control.

  • Page 94

    Modify the parameter “Direct Link Port”: Select identified COM Port. Figure 8.14: Direct link port Open customer account AMAX panel 4000. Select index sheet “Link”. Select communication model “Direct Connect”. Click on Button “Connect” in order to connect to AMAX panel 4000.

  • Page 95: Modem Connection

    AMAX panel 4000 / AMAX panel 4000 Configuration | en Figure 8.15: Link-Direct Connect When connected to AMAX panel 4000, Button label changes to “Disconnect”. 8.6.2 Modem Connection Telephone Remote Connection The telephone remote connection function allows establishing a connection from the remote PC to the alarm control panel through telephone network to perform remote programming and control.

  • Page 96

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Number of rings (address 0144), callback telephone number (address 0146 - 0161) and telephone remote connection enabled (address 0145) are set on the alarm control panel. Run RPS on the remote PC and set relevant parameters in relevant operating interfaces.

  • Page 97

    AMAX panel 4000 / AMAX panel 4000 Configuration | en Figure 8.17: Customer Information – c. Select the latest version for the alarm control panel type of AMAX4000- in the alarm control panel setting tab page. Bosch Sicherheitsysteme GmbH Installation Guide...

  • Page 98

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Figure 8.18: Control Panel Configuration – d. Select “Communication and Report” in the “Control Panel Configuration” tab page. Set the SUBSCRIBER NUMBER of receiver 1. The SUBSCRIBER NUMBER must be in consistence with the SUBSCRIBER NUMBER of receiver 1 of the alarm control panel.

  • Page 99

    AMAX panel 4000 / AMAX panel 4000 Configuration | en – Or manual dialing connection: Select “Modem Connection” in the “Connection” tab page and click “Waiting for Callback”, then initiate callback call from the alarm control panel with keypad: Enter SUBSCRIBER NUMBER, press [5] [7] and then [#].

  • Page 100: Ip Connection

    AMAX panel 4000 / AMAX panel 4000 en | Configuration After successfully connected, RPS can execute multiple operations, including reading/writing control panel parameters, remote arming/disarming, viewing log, etc. After the telephone is successfully connected, RPS will disconnect it with the alarm control panel after 5 minutes of idling.

  • Page 101

    AMAX panel 4000 / AMAX panel 4000 Configuration | en Figure 8.20: Communication Setting – b. Click “New Customer” in “Customer” to create customer. Enter relevant customer information in the “Customer Information” tab page. The “Customer Number” must be entered. The IP address and port number of the alarm control panel are the IP address and port number of the communication module 1 installed in the alarm control panel, and will be used when the alarm control panel uses fixed IP and port number.

  • Page 102

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Figure 8.21: Customer Information – c. Select the latest version for the alarm control panel type of AMAX4000 in the alarm control panel setting tab page. 2013.07 | 03 | F.01U.267.112...

  • Page 103

    AMAX panel 4000 / AMAX panel 4000 Configuration | en Figure 8.22: Control Panel Type – d. Select “Communication and Report” in the “Control Panel Configuration” tab page. Set the SUBSCRIBER NUMBER of receiver 1. The SUBSCRIBER NUMBER must be in consistence with the SUBSCRIBER NUMBER of receiver 1 of the alarm control panel.

  • Page 104

    AMAX panel 4000 / AMAX panel 4000 en | Configuration – Or manual IP connection: Select “Network Connection” and click “Waiting for Callback” in the “Connection” tab page. Then initiate IP connection from the alarm control panel with keypad: Enter SUBSCRIBER NUMBER, press [5] [7] and then [#].

  • Page 105: Programming With The Icp-ezpk Programming Key

    After saving information in the programming key, you can easily program other AMAX panel 4000 / AMAX panel 4000 EN with the same programming data. You can also use the programming key to back up existing information.

  • Page 106: Firmware Upgrade With The Icp-ezru2 Upgrade Key

    AMAX panel 4000 / AMAX panel 4000 en | Configuration Connect the programming key to the plug marked as "PROGRAMMING KEY" on the top of the printed circuit board (PCB) of the alarm control panel. Please note that the direction of the programming key should be consistent with the direction marked on the PCB.

  • Page 107: Programming

    AMAX panel 4000 / AMAX panel 4000 Programming | en Programming The control panel programming options are stored in a non-volatile flash memory. This memory has all relevant configuration and user-specific data even after a total power loss. Because the data retention time is quite long without power, reprogramming is not required after powering up the control panel.

  • Page 108

    AMAX panel 4000 / AMAX panel 4000 en | Programming Transmission Format for Receiver (0 = Not used, 1 = 0113 Contact ID, 2= SIA, 3 = Conettix IP) Anti-replay for Receiver (0 = Disabled, 1 = Enabled) 0114 EN=1...

  • Page 109

    AMAX panel 4000 / AMAX panel 4000 Programming | en System Status Report (Zone fail, comm. fail, telephone 0124 EN=1/5/6/7 line fail, AC fail, low batterie...etc.) Keypad Panic Alarm Report 0125 Keypad Fire Alarm Report 0126 Keypad Medical Alarm Report...

  • Page 110

    AMAX panel 4000 / AMAX panel 4000 en | Programming Siren / PO 1+2 Supervision Address 0140 Address Default 0 = disabled, 1 = PO1 enabled, 2 = PO2 enabled, 3 = 0140 VDS-A EN=3 PO1+2 enabled Keypad 2 Button Alarm...

  • Page 111

    AMAX panel 4000 / AMAX panel 4000 Programming | en Remote PC Setting Address 0162 - 0179 Address Default RPC IP No 0162 - 0173 RPC Port Number 0174 - 0178 Control Panel DHCP Update Time (hours) 0179 RPC is the remote programming computer equipped with remote programming software.

  • Page 112

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Pulse Count Duration Address 0198 - 0200 Address Default 0 = Disable, 1-999sec = Duration 0198 VDS-A EN=000 Event Record Count per Set/Unset Period Address 0201 Address Default 3 - 10...

  • Page 113: Zone Programming

    AMAX panel 4000 / AMAX panel 4000 Programming | en Domestic Telephone Number 4 1666 - 1681 See Telephone Programming Parameters If the default 15 is set to the initial digit of the telephone number, domestic telephone alarm function is disabled; If set to other positions, it marks the end of the telephone number.

  • Page 114

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Pulse Count 0224 VDS-A EN=0 Zone Lockout 0225 Zone Tamper (DEOL) 0226 Zone Status Report 0227 VDS-A EN=1/5/6/7 Unverified Alarm Report / Cross Zone 0228 VDS-A EN=0 Domestic No.

  • Page 115

    AMAX panel 4000 / AMAX panel 4000 Programming | en Unverified Alarm Report / Cross Zone 0258 VDS-A EN=0 Domestic No. 0259 Zone Function # 05 Address Default Zone Type 0260 - 0261 Force Arm / Zone Bypass 0262 VDS-A EN=0/2...

  • Page 116

    AMAX panel 4000 / AMAX panel 4000 en | Programming Force Arm / Zone Bypass 0292 VDS-A EN=0/2 Silent Alarm / Chime Mode 0293 VDS-A EN=0/2 Zone Pulse Count 0294 VDS-A EN=0 Zone Lockout 0295 Zone Tamper (DEOL) 0296 Zone Status Report...

  • Page 117

    AMAX panel 4000 / AMAX panel 4000 Programming | en Zone Tamper (DEOL) 0326 Zone Status Report 0327 VDS-A EN=1/5/6/7 Unverified Alarm Report / Cross Zone 0328 VDS-A EN=0 Domestic No. 0329 Zone Function # 12 Address Default Zone Type...

  • Page 118

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Function # 15 Address Default Zone Type 0360 - 0361 Force Arm / Zone Bypass 0362 VDS-A EN=0/2 Silent Alarm / Chime Mode 0363 VDS-A EN=0/2 Zone Pulse Count...

  • Page 119

    AMAX panel 4000 / AMAX panel 4000 Programming | en Instant Report Reserved Force Arm / Bypass Disabled Force Arm Bypass Silent Alarm / Chime Disabled Mode Silent Alarm Chime Mode Zone Pulse count Disabled 1-9 Pulses Zone Lockout Disabled...

  • Page 120

    AMAX panel 4000 / AMAX panel 4000 en | Programming Report to Destination 2 Report to Destination 3 Report to Destination 4 Report to Destination 1 ,2, 3, 4 Report to Destination 1 (2, 3, 4 backup) Report to Destination 1 (2 Backup) and 3 (4 backup)

  • Page 121

    AMAX panel 4000 / AMAX panel 4000 Programming | en Zone Area, Zone Functions and Module Selection Zone Area Selection Default Zone Function Default Module Default Address Selection Selection Address Address 0678 - 0679 0806 0870 0680 - 0681 0807...

  • Page 122

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Area Selection Default Zone Function Default Module Default Address Selection Selection Address Address 0710 - 0711 0822 0886 0712 - 0713 0823 0887 0714 - 0715 0824 0888 0716 - 0717...

  • Page 123

    AMAX panel 4000 / AMAX panel 4000 Programming | en Zone Area Selection Default Zone Function Default Module Selection Default Address Selection Address Address 0742 - 0743 0838 0901 0744 - 0745 0839 0902 0746 - 0747 0840 0903 0748 - 0749...

  • Page 124: Output Programming

    AMAX panel 4000 / AMAX panel 4000 en | Programming 0804 - 0805 0869 0933 Value Range: 00 = zone Value Range:0–15. See 0 = On-board zone not used, 1 - 16 = Area 1- Section Zone Functions. 1 = Keypad Zone...

  • Page 125

    AMAX panel 4000 / AMAX panel 4000 Programming | en Output 3 Output Event Type 0526 - 0527 VDS-A EN=5 Output Area / Zone 0528 - 0529 Output Mode 0530 VDS-A EN=0 Output Time 0531 - 0533 VDS-A EN=180 Output 4...

  • Page 126

    AMAX panel 4000 / AMAX panel 4000 en | Programming All Faults Fire Alarm 0 = Any Area, 1 - 16 = Areas 1 - 16 Fire Reset AWAY Armed 0 = All Areas 1 - 16 = Areas 1 - 16...

  • Page 127

    AMAX panel 4000 / AMAX panel 4000 Programming | en Output Event Type 0542 - 0543 Output Area / Zone 0544 - 0545 Output Mode 0546 Output Time 0547 - 0549 Output 6 Address Default Output Event Type 0550 - 0551...

  • Page 128

    AMAX panel 4000 / AMAX panel 4000 en | Programming Output 12 Address Default Output Event Type 0598 - 0599 Output Area / Zone 0600 - 0601 Output Mode 0602 Output Time 0603 - 0605 DX3010 2 Output Programming Address 0606 - 0669...

  • Page 129: Access Codes

    AMAX panel 4000 / AMAX panel 4000 Programming | en Output 18 Address Default Output Event Type 0646 - 0647 Output Area / Zone 0648 - 0649 Output Mode 0650 Output Time 0651 - 0653 Output 19 Address Default Output Event Type...

  • Page 130

    AMAX panel 4000 / AMAX panel 4000 en | Programming User Codes User User Default/ Value Area Default / User Code Default Authority Range Selection Value Range Address Level Address Address # 01 1010 Default: 0 1011 - 1012 Default: 00...

  • Page 131

    AMAX panel 4000 / AMAX panel 4000 Programming | en 1226 1227 - 1228 1229 - 1234 1235 1236 - 1237 1238 - 1243 1244 1254 - 1246 1247 - 1252 1253 1254 - 1255 1256 - 1261 1262 1263 - 1264...

  • Page 132

    AMAX panel 4000 / AMAX panel 4000 en | Programming 1532 1533 - 1534 1535 - 1540 1541 1542 - 1543 1544 - 1549 1550 1551 - 1552 1553 - 1558 1559 1560 - 1561 1562 - 1567 1568 1569 - 1570...

  • Page 133

    AMAX panel 4000 / AMAX panel 4000 Programming | en Value Area Bosch Sicherheitsysteme GmbH Installation Guide 2013.07 | 03 | F.01U.267.112...

  • Page 134

    AMAX panel 4000 / AMAX panel 4000 en | Programming 2013.07 | 03 | F.01U.267.112 Installation Guide Bosch Sicherheitsysteme GmbH...

  • Page 135: System Programming

    AMAX panel 4000 / AMAX panel 4000 Programming | en Table 9.3: The Distribution of Personal Identification Number in Areas System Programming Exit Delay Area Address Default 0403 - 0405 0409 - 0411 0415 - 0417 0421 - 0423 0427 - 0429...

  • Page 136

    AMAX panel 4000 / AMAX panel 4000 en | Programming Entry Delay Area Address Default 0406 - 0408 0412 - 0414 0418 - 0420 0424 - 0426 0430 - 0432 0436 - 0438 0442 - 0444 0448 - 0450 0454 - 0456...

  • Page 137

    AMAX panel 4000 / AMAX panel 4000 Programming | en Keypad Keypad No. in Area Address Default 1586 - 1587 1588 - 1589 1590 - 1591 1592 - 1593 1594 - 1595 1596 - 1597 1598 - 1599 1600 - 1601...

  • Page 138

    AMAX panel 4000 / AMAX panel 4000 en | Programming Keypad Lockout Address 0499 Address Default 0 = disabled 1-15 times 0499 VDS-A EN=10 Quick Arming Address 0500 Address Default 0 = disabled 1= Enable 0500 VDS-A EN=0 Display and Prompt Tone of Date and Time Fault...

  • Page 139

    AMAX panel 4000 / AMAX panel 4000 Programming | en Siren Beep Arm/Disarm (RF Keyfob) Address 0945 Address Default 0 = disable 1 = Enable 0945 RF Keyfob Panic Option Address 0946 Address Default 0 = No alarm 1 = Silent alarm 2 = Non silent alarm...

  • Page 140

    AMAX panel 4000 / AMAX panel 4000 en | Programming RF ID Devices Sens Address Defaul Sensor Address Defaul Sensor Address Defaul 1700 – 1920 – 2140 – 1708 1928 2148 1710 – 1930 – 2150 – 1718 1938 2158 1720 –...

  • Page 141

    AMAX panel 4000 / AMAX panel 4000 Programming | en 1880 – 2100 – 2320 – 1888 2108 2328 1890 – 2110 – 2330 - 2338 1898 2118 1900 – 2120 – 1908 2128 1910 – 2130 - 1918 2138 Each RFID Device has nine digits.

  • Page 142

    AMAX panel 4000 / AMAX panel 4000 en | Programming Wireless Repeater RF ID Repeater Address Default 2340 – 2348 2350 – 2358 2360 – 2368 2370 – 2378 2380 – 2388 2390 – 2398 2400 – 2408 2410 - 2418 2013.07 | 03 | F.01U.267.112...

  • Page 143

    AMAX panel 4000 / AMAX panel 4000 Programming | en Transmitter RF ID Keyfob Address Keyfob Address 2420 – 2428 2740 – 2748 2430 – 2438 2750 – 2758 2440 – 2448 2760 – 2768 2450 – 2458 2770 – 2778 2460 –...

  • Page 144

    AMAX panel 4000 / AMAX panel 4000 en | Programming Keyfob Address Keyfob Address 3060 – 3068 3380 – 3388 3070 – 3078 3390 – 3398 3080 – 3088 3400 – 3408 3090 – 3098 3410 – 3418 3100 – 3108 3420 –...

  • Page 145

    AMAX panel 4000 / AMAX panel 4000 Programming | en All Keyfob RFID default values are 15. RF Key Fob assignment to Areas Number of Areas in the system Area Keyfobs Radion Keyfobs DSRF 1 – 128 1 – 24 1 - 64 1 –...

  • Page 146

    AMAX panel 4000 / AMAX panel 4000 en | Programming Number of Areas in the system Area Keyfobs Radion Keyfobs DSRF 49 – 64 10 – 12 65 – 80 13 – 15 81 – 96 16 – 18 97 – 112 19 –...

  • Page 147

    AMAX panel 4000 / AMAX panel 4000 Programming | en Number of Areas in the system Area Keyfobs Radion Keyfobs DSRF 107 – 117 21 – 22 118 – 128 23 – 24 1 – 11 1 - 2 12 – 22 3 - 4 23 –...

  • Page 148

    AMAX panel 4000 / AMAX panel 4000 en | Programming Number of Areas in the system Area Keyfobs Radion Keyfobs DSRF 57 – 65 13 – 14 66 – 74 15 – 16 75 – 83 17 – 18 84 – 92 19 –...

  • Page 149

    AMAX panel 4000 / AMAX panel 4000 Programming | en Number of Areas in the system Area Keyfobs Radion Keyfobs DSRF 81 – 88 89 - 96 97 - 104 105 - 112 113 - 120 121 - 128 Address 3700 - 3735...

  • Page 150

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Zone Name Adress Default 3736 - 3771 3772 - 3807 3808 - 3843 3844 - 3879 3880 - 3915 3916 - 3951 3952 - 3987 3988 - 4023 4024 - 4059...

  • Page 151

    AMAX panel 4000 / AMAX panel 4000 Programming | en Zone Zone Name Adress Default 4888 - 4923 4924 - 4959 4960 - 4995 4996 - 5031 5032 - 5067 5068 - 5103 5104 - 5139 5140 - 5175 5176 - 5211...

  • Page 152

    AMAX panel 4000 / AMAX panel 4000 en | Programming Zone Name may have up to 18 characters. Each character of the zone name uses 2 addresses. Example: A = 4 1, A = Address 3736 = 4, Address 3737 = 1 2013.07 | 03 | F.01U.267.112...

  • Page 153: Keypad Usage And Operations

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Keypad Usage and Operations 10.1 Keypad Operating Instructions IUI-AMAX4-TEXT IUI-AMAX3-LED8 IUI-AMAX3-LED16 IUI-AMAX-LED8 IUI-AMAX-LCD8 Bosch Sicherheitsysteme GmbH Installation Guide 2013.07 | 03 | F.01U.267.112...

  • Page 154

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations Quick Keypad Operation Instructions Function Command D A B S M I Arm / Disarm AWAY arm [Code] + [#] / [#] (Quick arm) √ √ √...

  • Page 155

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Function Command D A B S M I Other Commands Switch to Main Keypad [Code] + [0][0][0] + [#] (Text KP) √ √ √ Switch to Partition 01-16 [Code] + [0][ _ ][ _ ] + [#] √...

  • Page 156

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations Exits Progr. mode with save [9][6][0] + [#] (only in Address Progr. √ Mode) Set Factory Defaults [9][6][1] + [#] (only in Address Progr. √ Mode) Copy control panel data to [9][6][2] + [#] (only in Address Progr.

  • Page 157

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Keypad Indicators Keypad indicator Status Definition icons Zone is triggered. Zone is normal. Fast flash (0.25 seconds lights on/ Zone was alarmed or is in alarm 1 2 3 ….

  • Page 158: Arming And Disarming The System

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations Keypad Sounds Sound Indicator Definition One short beep A keypad button has been pressed. One single one- second beep The requested operation is refused. Incorrect operation signal.

  • Page 159: Disarming The System

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Telephone Remote Arming The user dials the control panel number. The control panel answers the call and issues a long beep. After the long beep, the user must press the [#] key. When the Panel receives the signal it will confirm the arming of the control panel with a high tone.

  • Page 160

    1 - 2 Panel Aux Power 1 - 2 Fault Bosch Option Bus Power Failure 1 - 2 Bosch Option Bus 1 - 2 Power Fault RF Repeater AC Power Failure 1 - 8 RF Repeater 1-8 AC Power Fault...

  • Page 161: System Fault Or Tamper Analysis Mode In Text Keypad

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Output Failure Onboard Output Failure 1 Onboard Output 1 Fault 2 Onboard Output 2 Fault Keypad Failure 1 - 16 Keypad 1 – 16 Fault System Failure...

  • Page 162: System Test

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations c) To exit from Fault and Tamper Analysis Mode, press [#]. 10.4 System Test 10.4.1 Siren Test This function allows the code holders to test the siren.

  • Page 163: Reset The Control Panel

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en Dialer Event Log Enter your code + [2] [4] and press [#]. It beeps twice. Press [▲] or [▼] to move up and down in the Event Logs Press [ #] To exit the Event Log 10.6...

  • Page 164: Codes

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations a) Enter your code + [3] [4] and press [#]. It beeps twice. Bypass Inquire The bypass inquires displays all bypassed zones. a) Enter your code + [3] [3] and press [#]. It beeps twice.

  • Page 165: Change Individual Code

    AMAX panel 4000 / AMAX panel 4000 Keypad Usage and Operations | en b) Enter the user number (1-64) and press [#]. c) Enter the user code priority (0-15) and press [#]. 00 = Master User 01 = Super User...

  • Page 166: Keypad Fire Alarm

    AMAX panel 4000 / AMAX panel 4000 en | Keypad Usage and Operations 10.9.2 Keypad Fire Alarm If you simultaneously press and hold [4] and [6] for 3 seconds a silent keypad fire alarm will be transmitted. Please contact your installer to enable/disable the fire alarm functionality.

  • Page 167: Troubleshooting

    AMAX panel 4000 / AMAX panel 4000 Troubleshooting | en Troubleshooting Problem Reason Solution No display on keypad after – AC power or battery fuse – Check if the AC power power up failure. and battery fuses are – Abnormal RBGY wiring.

  • Page 168

    AMAX panel 4000 / AMAX panel 4000 en | Troubleshooting AC power fault – AC power fuse is burnt. – Check if the 18V of the transformer is correctly wired and replace the fuse. Over current protection of the –...

  • Page 169

    AMAX panel 4000 / AMAX panel 4000 Troubleshooting | en Occasionally abnormal – Extension system is used – Add dial delay in communication in use of in the telephone programming. Contact ID/personal network. – Connect the system after telephone alarm.

  • Page 170: Maintenance

    AMAX panel 4000 / AMAX panel 4000 en | Maintenance Maintenance 2013.07 | 03 | F.01U.267.112 Installation Guide Bosch Sicherheitsysteme GmbH...

  • Page 171: Technical Data

    AMAX panel 4000 / AMAX panel 4000 Technical Data | en Technical Data Panel Enclosure: Dimensions (HxWxD): – 375 x 322 x 88 mm(L x W x H) Weight: – 4700g Environmental Considerations: Relative Humidity: – 10%-95% Operating Temperature: –...

  • Page 172

    AMAX panel 4000 / AMAX panel 4000 en | Technical Data B 426 or DX 4020 or DX – 4020G (only 1): DX2010: – DX 4010: – RF Receiver: – RF Repeater: – DSRF = 0, Radion = 8 RF Sensors: –...

  • Page 173

    AMAX panel 4000 / AMAX panel 4000 Technical Data | en Panel PCB: – Quiescent current maximum 100mA Battery: – 12V/7 Ah, lead acid rechargeable – 12V/17Ah, lead acid rechargeable – Low battery condition is below 11,0 VDC – Minimum battery condition is 10,8VDC Certification: –...

  • Page 174

    AMAX panel 4000 / AMAX panel 4000 en | Technical Data Current Consumption: – standby 31mA – maximum 60mA Cable requirements: – four wire, AWG18 or AWG22 – maximum length 200m (Panel to last KP) – maximum BUS 1 length 700m (max 14 devices, 8 KPs) –...

  • Page 176

    Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2013...

This manual also for:

Amax panel 4000 en

Comments to this Manuals

Symbols: 0
Latest comments:
