AMAX panel

AMAX panel 2100 | AMAX panel 3000 | AMAX panel 3000 BE | AMAX panel 4000

Installation Manual

Table of Contents

Summary of Contents for Bosch AMAX panel 2100

Page 1 All manuals and user guides at all-guides.com AMAX panel AMAX panel 2100 | AMAX panel 3000 | AMAX panel 3000 BE | AMAX panel 4000 Installation Manual...
Page 2 All manuals and user guides at all-guides.com...
Page 3: Table Of Contents
All manuals and user guides at all-guides.com AMAX panel Table of Contents | en Table of contents Safety Short Information Keypad Indicators System overview Optional Modules and Peripheral Devices Bosch Option Bus Keypad 4.2.1 General 4.2.2 Address Setting 4.2.3 Wiring 4.2.4...
Page 4 Keypad Lockout System 6.5.1 System Setting 6.5.2 System View 6.5.3 System Factory Default Outputs and Sirens 6.6.1 Outputs 6.6.2 Sirens RF Devices 6.7.1 RF Options 6.7.2 RF Devices / User 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 5 Output and Siren Programming 8.6.1 Output Programming 8.6.2 Siren Programming RF Device Programming Troubleshooting General Trouble Trouble Fault Inquiry Maintenance 10.1 Firmware Upgrade with the ICP-EZRU2 Upgrade Key Technical Data Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 6: Safety
Damage or contamination of the system is possible if the battery is not handled correctly or if the battery is not replaced on a regular basis. – Only use a non-spillable battery. – Place a label with the last replacement date on the battery. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 7 It is recommended to test the system once a week. – Make sure to get the system maintained four times a year. – Only qualified installers /service personnel are allowed to maintain this system. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 8: Short Information
STAY indicator flashes simultaneously. System is armed in STAY mode. System not armed in STAY mode. Slow flash (1 second lights on/1 Exit time. STAY second lights off) 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 9 Continuous 0.5 second beep, stops – Entry delay time (until alarm ends or system is for 0.5 seconds disarmed) – Exit delay time (stops 10 seconds before exit delay stops) Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 10: System Overview
LCD / LED Keypad Text Keypad DX2010 Option Bus B450 B426 DX3010 DX4010V2 DX4020G (B442/B443) GSM/ Ethernet GPRS GPRS PSTN Video A-Link Plus Figure 3.2: AMAX 3000 BE / 4000 Overview 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 11 All manuals and user guides at all-guides.com AMAX panel System overview | en Wiring diagrams ≤ 500mA / B450 Figure 3.3: Wiring diagram AMAX 2100 / 3000 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 12 On: Trouble state Off: Trouble state PO-5 1 Tamper Switch 2 Zone Switch 3 EOL 2,2 k 4 NO + NC Figure 3.4: Wiring diagram AMAX 3000 BE / 4000 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 13: Optional Modules And Peripheral Devices
Optional Modules and Peripheral Devices Bosch Option Bus The AMAX panel provides BOSCH option bus 1 and option bus 2 (only for AMAX 3000 BE and AMAX 4000) to connect modules and devices. Each module can be connected to each bus.
Page 14: Keypad
Address setting for IUI-AMAX4-TEXT, IUI-AMAX3-LED16 and IUI-AMAX3-LED8 Keypads For IUI-AMAX4-TEXT, IUI-AMAX3-LED16 and IUI-AMAX3-LED8 keypads, the address of the keypad is programmed with 6-position DIP switch. The address of each keypad is unique. DIP Switch Keypad Address 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 15: Wiring
200m. AMAX 2100 / 3000 Keypad AMAX 3000 BE / 4000 Figure 4.2: Connecting a keypad to the AMAX Panel Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 16: Status Indicator
57 - 64 Table 4.4: DX2010 Address Settings DIP Switch Data Bus Address 102*** 103** 104** 105* 106* 107* 108* Table 4.5: DX2010 DIP Switch Settings * AMAX 3000 BE / 4000 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 17: Wiring
Trouble Condition: – Grounding Conductor is not connected or there is a communication failure between the module and the AMAX panel – No zones distributed – Module address setting error Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 18: Dx3010
The following table and graphic show how to wire DX3010 to the option bus of the AMAX panel. Power Supply Wire diameter of 0.8mm Wire diameter of 1.2mm AMAX panel 12.2m 24.4m External power supply 305m 610m Table 4.9: Lengths of cable for DX3010 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 19: Status Indicator
4.5.3 Wiring The following graphic shows how to wire B426 to the option bus 1 or 2 of the AMAX panel. Make sure, that the cable doesn’t exceed 150 meters. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 20: Status Indicator
Conettix IP protocol with full authentication, 256 bit AES encryption and resistance to Denial of Service attacks. B450 also supports compatible Bosch panels using SIA DC-09, CSV-IP. It is a reliable way to add cellular network communications to existing or new commercial security and fire installations.
Page 21: Address Setting
Power failure or other failure conditions Status LED of B442 or Stable flash Normal Operation B443 3 quick flashes Communication error Power failure or other failure conditions Table 4.11: B450 with B442 System Status Indicator Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 22: Dx4010V2
GPRS network. Transmission of alarm information via GPRS is the default for ITS- DX4020-G. SMS or USB mode can be chosen for configuration. Remote programming and control of the AMAX panel is supported. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 23: Address Setting
Normally, the AMAX panel tests the communication with the module. In case of a communication failure, a fault report including the module address is sent. The following table describes the status LED indicator of DX4020-G. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 24: Rf Radion Receiver
Normal operation Stable flash Receiver is being programmed with the zone and transmitter IDs from the AMAX panel. Turns off momentarily Receiver has obtained a valid transmission from a RADION transmitter. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 25 A communication failure between the AMAX panel and the receiver or – An invalid address switch setting Power failure or wiring failure Table 4.13: RFRC-OPT Radion Receiver System Status Indicator Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 26: Installation
Expansion modules can be placed in the enclosure of the AMAX panel. Several places are available. Figure 6.1. and figure 6.2 show the standard enclosure installation and the enclosure installation with a mounting plate. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 27: Battery Installation
Danger! Battery Injuries due to electric shock, fire or explosion are possible if the battery is handled or connected incorrectly. – Always handle the battery carefully and replace it carefully. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 28: System Power Up
The language setting menu is displayed. Set the date and time. Otherwise, the system prompts as fault. After the AMAX panel is powered up or reset, it resets to previous arming / disarming status. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 29: System Status Indicator
Remove the EN indication (on label) if the system is set without EN parameters. – Connect no more than 10 devices to one zone input (Panel, Keypad, Input Module, RFUN, …) Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 30: 50131-3 Grade 2, Environmental Class 2 - Amax 2100 / 3000 / 3000 Be / 4000
E-mail: certification@afnor.org Certification Body: CNPP – Certification Department – CNPP Cert. Route de la Chapelle Réanville CS 22265 27950 SAINT MARCEL Tel: + 33 (0) 2 32 53 63 63 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 31 For further information about the sealing wire and the adhesive seal, please reverse directly to your local Bosch contact. Sealing the enclosure with a sealing wire Open the pre-opened hole which is on the right of the enclosure.
Page 32: Incert - Amax 4000
SFF – AMAX 2100 / 3000 / 3000 BE / 4000 Certification Body: VDS Schadenverhütung Amsterdamer Str. 172 50735 Köln Website: www.vds.de Certification Body: SSF Stöldskyddsföreningen Tegeluddsvägen 100 115 87 Stockholm Website: www.stoldskyddsfpreningen.se 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 33 All manuals and user guides at all-guides.com AMAX panel Installation | en The panel complies with the following standards: SSF 1014 Edition 4 Alarm class 1 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 34: Settings
Example You can set up dialer 1 to report to receiver 1 in Bosch Network (Conettix) format and set up dialer 2, dialer 3, and dialer 4 to report to a receiver of a central monitoring station in Contact ID format only, if dialer 1 is unsuccessful.
Page 35 If a subscriber ID number has less than 6 digits, use 0 to full fill the data in the higher bits. Example Program subscriber ID number as 4729 in six addresses: [0 0 4 7 2 9] Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 36 Which communication protocols can be used in a particular case depends on the receiver of the provider. Therefore, contact your provider. The following table shows an overview of the available communication features for each communication protocol. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 37 √ √ BURG ALARM 1130 √ √ √ √ BURG ALARM RESTORE 3130 √ BURG 24-HOUR 1133 √ √ √ √ BURG 24-HOUR RESTORE 3133 √ SENSOR FAULT 1380 √ Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 38 EXTERNAL MODULE TAMPER 1341 √ √ EXTERNAL MODULE TAMPER RESTORE 3341 √ DATE TIME SET 1625 √ √ USER CODE CHANGE √ √ ENTER PROGRAM MODE √ EXIT PROGRAM MODE √ 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 39 √ PRINTER MISSING 1336 √ PRINTER MISSING RESTORE 3336 √ PRINTER ERROR 1335 √ PRINTER ERROR RESTORE 3335 √ PRINTER MODULE MISSING 1333 √ PRINTER MODULE MISSING RESTORE 3333 √ Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 40 RF KEYFOB PANIC ALARM 1120 √ RF KEYFOB SILENT ALARM 1122 √ RF CHANGE KEYFOB √ RF POINT ENCLOSURE TAMPER 1383 √ √ √ RF POINT ENCLOSURE TAMPER RESTORE 3383 √ 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 41: Reports
The AMAX panel can save up to a maximum of 50 un-reported events. If the un- reported events are more than 50, it will delete earlier event and only save the last 50 events in the buffer to send out. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 42 The non 24-hour zone fault recovery report will be sent when the zone recovers or the system disarms. For the 24-hour zone, only the alarm recovery event will occur. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 43 The perimeter disarming report is sent at the disarming command and the perimeter arming report is sent when the arming succeeds. Quick Arming Sends perimeter arming report when the keypad is used for quick arming. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 44 Activate alarm siren and other alarm outputs – Lock the keypad in which the incorrect codes have been entered for 3 minutes – Send an access denial report On-board Output 1 – 2 Fault 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 45: Automatic Test Report
Dual IP Settings are valid only when used with Conettix IP communication format. IP module 1 is ITS-DX4020-G module or B426 module; IP module 2 is B426 module. IP module 2 does not support RPC connection. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 46: Remote Access
To program the IP address “10.16.1.222:80”, enter the following sequence into the correspondent address: [0 1 0 0 1 6 0 0 1 2 2 2 0 0 0 8 0] 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 47: Call Back And Domestic Call
[*] or [#]). If the AMAX panel got the [#] acknowledgement from the user, it will send a 2 seconds long confirmation beep as an acknowledge tone and hang up the line. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 48: Ring Times
For example: If 01 and 02 is selected in this option, area 01 and 02 is assigned. Keyfobs are also assigned to area 01 and 02. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 49: Installer Code
[code] + [2-digit area no.] + [#] √ √ √ master keypad STAY Arm [code] + [*] / [*] for 3 sec. (quick arm) √ √ √ √ √ √ √ Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 50 √ √ √ √ √ [code] + [3] [1] + [#] (cancel LED keypad) √ √ √ √ √ Bypass Fault/Tamper [code] + [3] [4] + [#] √ √ √ √ 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 51 Exit Programming Mode [9] [5] [9] + [#] √ without saving Exit Programming Mode with [9] [6] [0] + [#] √ saving Set Factory Default [9] [6] [1] + [#] √ Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 52: Code Length
This option enables/disables the quick play function of the macro. If this function is enabled, the user can press the number of the macro for three seconds to execute the macro playing function without entering a code. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 53: Code Reporting
The following zone types can be selected for the zone function of each zone. Zone Function Option Description Zone Type Not used Instant Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 54 Disarm: – Zone normal - no alarm / no report – Zone triggered - no alarm / no report AWAY Arm: – Zone normal - no alarm / no report 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 55 04 – Interior Delay 1 The interior delay 1 zone type performs as described below: Disarm: same as the instant zone disarm status AWAY Arm: same as the delay zone AWAY arm status Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 56 When system is disarmed and zone is not restored before, a zone restore report is sent. 08 – Interior Delay 2 The interior delay 2 zone type performs as described below: Disarm: same as the instant zone disarm status 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 57 12 – Interior Follower The interior follower zone type performs as described below: Disarm: same as the instant zone disarm status AWAY Arm: same as the follower zone AWAY arm status Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 58 Wiring diagram for key-switch zone: short for arm. The momentary time is capable of lasting Minimum 300ms. Zone Wiring diagram for key-switch zone: open for arm. The momentary time is capable of lasting Minimum 300ms. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 59 18 – 24-Hour Panic The 24-hour panic zone type performs as described below: Disarm: – Zone normal - no alarm / no report – Zone triggered – silent alarm / report AWAY Arm: Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 60 STAY Arm: same as AWAY arm performance – A tamper zone does not send a restore report until the zone is restored. 22 – Bolt Contact The bolt-contact zone type performs as described below: 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 61 Zone normal - no alarm / no report – Zone triggered – performs system reset / no report AWAY Arm: – Zone normal - no alarm / no report STAY Arm: same as AWAY arm performance Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 62 1650 2200 2750 normal 2970 ∞ triggered The detectors (sensors) will be connected between zone and COM terminal through EOL series (open triggered) or parallel connection (short triggered). Zone 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 63 . , ' ? ! " 1 - ( ) @ / : _ ¹ ² ³ © ® º « » µ ¶ a b c 2 æ å ä à á â ã ç ć č d e f 3 è é ê ë ð ę Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 64: Pulse Count Duration
Disabled 1-9 pulses Zone lockout Disabled 1 times alarm lockout 3 times alarm lockout 6 times alarm lockout Alarm duration Zone tamper Disabled Enabled Zone status report No report required 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 65 If this option is selected, the system can be armed when the zone is in triggering status. If this option is not selected, the system does not allow the user to arm the system unless the zone with problems has resumed to normal status or been manually bypassed. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 66 If the zone detects that the 24-hour tamper is triggered, the zone tamper alarm will be processed the same as 24-hour zone. If the zone detests zone alarm, the zone will process according to specified zone type. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 67 When the first zone or one of the other zones (with cross zone option) is / are triggered twice or more after cross zone time is expired, the timer restarts Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 68: Zone Indication Keypad And Event Log
After disabling zone 5, zone number 17 is indicated on the LED/LCD keypad as zone number The following table shows the area assignment and keypad indication of zones in a multi area system: Zone Number Area Indication keypad area 1 Indication keypad area 1 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 69: Keypads And Areas
For example: The zones 1, 2, and 3 of 1 area or area 1 displayed on the keypad are actually zones 20, 31, and 37. 6.4.2 Area Timing The AMAX panel supports separate entry and exit delay times for each area. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 70: Common Area
The number of attempts to enter a wrong user code can be set from 1 to 15 in order to supervise valid user access. The keypad will be locked for 3 minutes, when the number of attempts reaches the declared value. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 71: System
If this option is disabled, a communication fault indication has to be reset manually after the communication is restored. Phone Fault Auto Reset This option enables/disables the automatic phone fault reset function. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 72 In case of a system tamper event, all keypads indicate an alarm. This option defines the behavior of the alarm on the keypad for area 01 if the alarm is acknowledged on a master keypad. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 73 VOICE YES is selected, all recorded voice messages are deleted and the default tone is used for domestic calls. For more information on recorded messages and domestic calls, refer to Call back and Domestic Call, page 47. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 74: System View
Example: 2 – 1, which indicates a panel AC failure. If necessary press [0] to return to step 2. Press [#] to exit. The STAY and AWAY indicators are extinguished and the FAULT indicator is lit. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 75: System Factory Default
Each output is programmable and can be set to follow multiple events. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 76 Zone number 1 – 64* RF Keyfob Button 3 (e.g. garage 0 = Any area door) 1 – 16 = areas 1 – 16* RF Keyfob Button 4 (e.g. light) Chime Indication 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 77 If the output time is set to 000, the output will continue until the system is disarmed. 03 - System Alarm This output is operated when an alarm occurs. The output is reset in the following cases: – The system is disarmed and alarm is reset. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 78 / 24h (can be silenced) / fire (can be silenced) / technical alarm (can be silenced)) occurs. – The system is in AWAY mode and a tamper alarm occurs. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 79 If the output time is set to 000, the output will continue until the AC power supply is restored and the fault is reset. 12 – Battery fault This output is operated when a low battery fault occurs. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 80 21 - Follow Zone Event Zone Number This output imitates the zone alarm state. The output is operated when an alarm or a tamper is generated in the corresponding zone. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 81 The output is reset when the medical alarm is reset or the output time ends. 34 – RF Power Fault The output is operated in the following cases: – The battery of the RF transmitter is low. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 82: Sirens
Enables / disables internal siren beep as indication when the system is armed, disarmed, or programming mode is entered. Silence Warning Device When Disarmed Enables / disables silence warning device when disarmed or by pressing any key. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 83: Rf Devices
When the repeater RFID is asked for, press [*] for 3s to toggle between AUTO and MANUAL mode. When MANUAL is selected, enter the 9-digit RFID manually. When AUTO is selected, trigger the RF device and the RFID is entered automatically. RF Sensor Diagnose Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 84: Key Programming
Unplug the programming key from the AMAX panel. LED/LCD keypads can also be used to copy the AMAX panel parameters to key parameters. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 85 AMAX panel again. Unplug the programming key from the AMAX panel. LED/LCD keypads can also be used to copy key parameters to the AMAX panel. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 86: Configuration
Press [–] to get to the EXIT PROG. +SAVE menu. It is optional to save or not to save the programming data. Select EXIT PROG. +SAVE and press [#] to save the data and to exit the programming mode. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 87 000 = No time limit 001 - 255 = 1 - 255 minutes EN=0 RPT DEL. ENTRY T:s SSI,EN=30 PANIC 2BUTTON AL 0-disabled FIRE 2BUTTON AL 1-report 2-siren MEDICAL 2BUTTON AL 3-all Figure 7.1: Communications and Reporting Manager Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 88 If you call again within 45 sec, the control panel answers the call on the first ring. Figure 7.2: Communications and Reporting Manager (continued) 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 89 0-disable 1-enable ARM/DISARM INSTAL. 0-disable 1-enable MACRO CONFIG INPUT MACRO (1-3) LEVEL 1 ACCESS 0-disable 1-enable REC T.OUT:1-80sec PAUSE T:100ms 1-15 CODE INSIDE MACRO 0-disable 1-enable Figure 7.3: Code Manager Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 90 ZONE PULSE COUNT 00 = disabled 01 - 09 Pulses EN=0 0-disabled ZONE LOCKOUT 1-1 time al. lock EN=0 2-3 time al. lock 3-6 time al. lock Figure 7.4: Zone Manager 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 91 10-dest. 3,4 11-dest 3 /4 b DETECT. T. x100ms PULSE COUNT DURAT. 000 = disabled 1 - 999 sec = Duration EN=0 CROSS ZONE TIMER Figure 7.5: Zone Manager (continued) Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 92 KEYPAD ALARM TONE 0-disable 1-enable AUDIB ENTRY ENABLE 0-disable 1-enable STAY ZONE AL INDIC 0-disable 1-enable BACKL. ON ENTRY T. 0-disable 1-enable KEYPAD LOCKOUT EN=10 Figure 7.6: Keypad and Area Manager 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 93 DEFAULT VOICE NO SYSTEM VIEW FAULT ANALYSIS FW VERSION FACTORY DEFAULT DEFAULT PANEL YES FACTORY DEFAULT DEFAULT PANEL NO DEFAULT OPTION FACT. DEF. ENABLE 0-disable 1-enable Figure 7.7: System Manager Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 94 SIREN SETTINGS SIREN TIME: min Master Timer for Outputs SIREN BEEP ENABLE 0-disable 1-enable INT SIREN INDIC ON 0-disable 1-enable SIREN OFF ANY KEY 0-disable 1-enable Figure 7.8: Output Manager 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 95 3s for MANUAL. Trigger device, RFID will be entered RF SENSOR DIAGNOSE RF ZONE No: RF REPEATER DIAGN. REPEATER No: 1-8 CLEAR CONFIRM CLR ALL RF DEVICES CLEAR CANCEL Figure 7.9: RF Manager Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 96 COPY DATA TO PANEL copy data from blue programming key to Panel COPY DATA TO KEY copy data from Panel to blue programming key Figure 7.10: Address and Key Programming 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 97: Led/Lcd Keypad Programming
Enter [959] and press [#] to exit programming mode without saving the data. For LED/LCD keypads, the programming data is displayed by the number indicators, as described in the graphic below. Programming Data Indicators Data Zone Indicators Value Mains Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 98: Pc Programming
Make sure that the value for subscriber number 1 is the same as currently programmed in AMAX panel as receiver 1. The value is 000000, when the firmware of the AMAX panel was upgraded or when the AMAX panel has factory settings. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 99 Make sure that the value for the parameter Installer code is the same as currently programmed in the AMAX panel. The value is 1234, when firmware of the AMAX panel was upgraded or when the AMAX panel has factory settings. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 100: Direct Connection
USB port of the PC running the A-Link Plus software. Install the USB driver. The device driver is located in the A-Link plus software path (example: C\\program files (x86)\Bosch Security System\A-Link Plus\USB_DRIVER). The installation creates an additional COM device on the PC.
Page 101 Figure 7.13: Selecting Communication Settings The Communication Setting dialog box opens. Make sure that the value for direct link port is the same as the port created by the USB driver installation. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 102 Select Customer –New Customer from the menu bar of the A-Link Plus program. The Customer Information index sheet opens. Select the Link index sheet. Select the communication model Direct Connect. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 103: Modem Connection
Run RPS on the remote PC and set relevant parameters in relevant operating interfaces. Select File - Communication Settings. The Communication Setting dialog box opens. Set the modem related parameters. Click on the Save button. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 104 Enter relevant customer information. The Customer Number is mandatory. Enter the telephone number connected to the AMAX panel in Control Panel Phone Number. The AMAX panel telephone number does not need to be set for manual connection. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 105 Click on the Wait for Incoming Call button. Initiate callback call from the AMAX panel via the keypad: Enter the subscriber number and press [5] [7] + [#]. The computer is connected to the AMAX panel. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 106: Ip Connection
Select the local IP address. If there are multiple IP addressed in the pull-down list, ensure to select the latest local IP address and enter the local port. For more information refer to Communication Operations Programming, page 115. Click on the Save button. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 107 The prompt information will recommend the subscriber number and the AMAX panel receives the IP address and port number of last time. Under DHCP environment, it is not necessary to set Control Panel IP address and Control Panel Port. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 108 The computer is connected to the AMAX panel. Notice! In case of a low transfer rate of the network or if a DX4020-G module is used, select the option Specific network. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 109 After the IP address is successfully connected, RPS will disconnect from the AMAX panel after 5 minutes of idling if you select the “Auto disconnect when idle connection exceeds 5 minutes” option. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 110: Address Programming
ID number via address programming or via installer menu programming. Digit required Number to program via Button to press via installer address programming menu programming 0 - 9 0 - 9 0 - 9 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 111 Subscriber ID number 0047 – 0052 000000 Anti-replay for receiver 0054 EN=1 Acknowledge wait time for receiver 0055 – 0056 Network polling time for receiver 0057 – 0059 DC09 data format 0260 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 112 Subscriber ID number 0107 – 0112 000000 Anti-replay for receiver 0114 EN=1 Acknowledge wait time for receiver 0115 – 0116 Network polling time for receiver 0117 – 0119 DC09 data format 0500 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 113: Reports Programming
EN=1/5/6/7 System status report (zone fail, comm. fail, telephone line 0123 EN=1/5/6/7 fail, AC fail, low battery and so on.) Keypad panic alarm report 0124 Keypad fire alarm report 0125 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 114 6 = destination 1 (2, 3, 4 for backup), 7 = destination 1, 3 (2, 4 for backup)) AC Fault Report by Receiver Option Address Default AC fault report by receiver (0 – 7) 0138 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 115: Communication Operations Programming
Remote PC IP address 0930 – 0941 Remote PC port number 0942 – 0946 AMAX panel DHCP update time (hours) 0947 Remote Programming (0 = disabled, 1 = enabled) 0970 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 116 After 8 seconds the control panel is called again and answers to the first ring. 15 = The control panel is called and the phone is allowed to ring only four times.) 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 117: User And Code Programming
2) Area selection 6018 – 6021 0000 Macro play right 6022 User code 6023 – 6028 258100 Keyfob RFID 6029 – 6037 Keyfob button 3 option 6038 reserved 6039 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 118 The default values for user 04 to 250 are the same as the default values of user 03. The following addresses are used for programming the users 04 to 250: 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 119 8248 – 8270 6753 – 6775 7512 – 7534 8271 – 8293 6776 – 6798 7535 – 7557 8294 – 8316 6799 – 6821 7558 – 7580 8317 – 8339 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 120 10525 – 10547 9030 – 9052 9789 – 9811 10548 – 10570 9053 – 9075 9812 – 9834 10571 – 10593 9076 – 9098 9835 – 9857 10594 – 10616 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 121: Installer Code Programming
The code length is always the same for the user and for the installer code. 8.2.4 Code Permission Programming Tamper Reset by User Option Address Default Tamper reset by User (0 = disabled, 1 = enabled) 1601 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 122: Macro Programming
1640 – 1642 * This function is relevant only if the macro without code function is disabled. ** This function can not be changed via the programming menu, only via address programming. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 123: Zone Programming
3 = RF all, 4 = RF RFGB glassbreak, 5 = RF RFUN no magnet, 15 = not used Zone no. Address Default Zone no. Address Default 1464 1480 1465 1481 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 124 In a one area system keypad the zone number 17 is indicated on an 8 zone LED/LCD keypad. After disabling zone 5, zone number 17 is indicated on the LED/LCD keypad as zone number 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 125 1384 1416 1385 1417 1386 1418 1387 1419 1388 1420 1389 1421 1390 1422 1391 1423 1392 1424 1393 1425 1394 1426 1395 1427 1396 1428 1397 1429 1398 1430 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 126 1288 – 1289 1352 – 1353 1290 – 1291 1354 – 1355 1292 – 1293 1356 – 1357 1294 – 1295 1358 – 1359 1296 – 1297 1360 – 1361 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 127 3744 – 3779 4896 – 4931 3780 – 3815 4932 – 4967 3816 – 3851 4968 – 5003 3852 – 3887 5004 – 5039 3888 – 3923 5040 – 5075 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 128: Zone Function Programming
A = 4 1, A = Address 3736 = 4, Address 3737 = 1 o = 6 15, k = 6 11 8.3.2 Zone Function Programming Zone function Option Address Default Selection of a zone type (00 – 26)* 1000 – 1001 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 129 Allow bypass/force arm 1017 VDS-A following zone EN=0/2 functions 02 to Silent alarm/chime mode 1018 VDS-A EN=0/2 Pulse count 1019 VDS-A EN=0 Zone lockout 1020 Zone DEOL 1021 Report 1022 VDS-A EN=1/5/6/7 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 130 1092 – 1103 3003160 00003 Selection of a zone type* 1105 – 1106 Remaining options as shown above 1107 – 1118 3003160 00003 Selection of a zone type* 1120 – 1121 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 131: Pulse Count Duration Programming
Pulse count duration (0 = disabled, 1 – 999 = 1 – 999 1606 – 1608 VDS-A seconds) EN=000 8.3.4 Zone Cross Timer Programming Option Address Default Zone cross timer (1 – 999 = 1 – 999 seconds) 1594 – 1596 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 132: Keypad And Area Programming
0863 – 0865 30 10 * 0866 – 0868 0869 – 0871 30 0872 – 0874 30 11 * 0875 – 0877 0878 – 0880 30 0881 – 0883 30 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 133: Common Area Programming
Keypad Indication Programming Option Address Default Keypad alarm tone (0 = disabled, 1 = enabled) 0622 Audible entry delay warning when STAY armed (0 = 1667 disabled, 1 = enabled) Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 134: Keypad Lockout Programming
Phone fault auto reset (0 = disabled, 1= enabled) 1673 General fault auto reset (0 = disabled, 1= enabled) 1674 Quick Arm Programming Option Address Default Quick arming (0 = disabled 1= enabled) 1597 VDS-A EN=0 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 135 Keypad 2 button medical alarm (0 = disabled, 1 = report, 0995 2 = siren, 3 = all) System Tamper Indication Option Address Default System tamper indication in area (0 = area 1, 1 = all 1610 areas) Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 136 Every character in this table has a row index and also a column index. – Row index is the first, and column index is the second value for each character. " & < > ‛ 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 137: System Factory Default Programming
Output parameter (area/zone no.) 0627 – 0628 Output pulse (0 = continuous, 1 = pulse, 3 = 0629 continuous inverted) Output time (seconds) 0630 – 0632 Selecting the output event* 0633 – 0634 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 138 0769 – 0776 0697 – 0704 0737 – 0744 0777 – 0784 Notice! When the zone activating alarm is programmed as a silent alarm, keypad and audible alarm have no output. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 139: Siren Programming
5256 – 5265 5576 – 5585 5266 – 5275 5586 – 5595 5276 – 5285 5596 – 5605 5286 – 5295 5606 – 5615 5296 – 5305 5616 – 5625 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 140 5566 – 5575 5886 – 5895 Wireless Repeater RFID RFID for wireless Address Default (ten digits, repeater no. 15 = not in use) 5896 – 5905 5906 – 5915 5916 – 5925 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 141 All manuals and user guides at all-guides.com AMAX panel Address Programming | en 5926 – 5935 5936 – 5945 5946 – 5955 5956 – 5965 5966 – 5975 Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 142: Troubleshooting
The tamper switch is not circuit jumper connected – Connect modules for – External module should programming such as be used for DX2010, DX3010, B426, programming, but it not or ITS-DX4020-G actually connected 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 143 0144 to a number from 1 address 0144 is set to 0) to 15 – There are multiple areas – The telephone arming is in the system available when the system has area 1 only Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 144: Trouble Fault Inquiry
Network/IP module 1 failure 1 - 2 Network/IP module 1 - 2 failure Output expansion module failure 1 - 2 Output expansion module 1 – 2 fault Input expansion module failure 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 145 1 - 2 Panel Aux power 1 – 2 fault Bosch option bus power failure 1 - 2 Bosch option bus 1 – 2 power fault RF repeater AC power failure 1 - 8 RF repeater 1 – 8 AC power fault RF repeater battery failure 1 –...
Page 146 * In case one or more faults occur in this category Fault Description 1 - Accessory Module Failure – Network/IP Module 1-2 Failure Condition: No communication with the DX4020 / ITS-DX4020G if DX4020 / ITS-DX4020G is available. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 147 Slow flash FAULT indicator (refer to Keypad Indicators, page 8 for a detailed description). When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off, when there is no other system fault. Printer Missing Condition: Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 148 The FAULT indicator is turned off when there is no other system fault. RF Receiver 1 Jammed Condition: A signal is disturbing the receiver if a wireless module is enabled. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 149 Report the repeater missing fault to configured destination when the fault is detected. Slow flash FAULT indicator (refer to Keypad Indicators, page 8 for a detailed description). When the fault is reset, send the restored report to the configured destinations. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 150 If the AC supply is not restored one hour after the fault occurred, report the fault to configured destination on address 124. Slow flash FAULT indicator (refer to Keypad Indicators, page 8 for a detailed description). 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 151 Bosch Option Bus Power 1-2 Failure Condition: Bosch option bus power supply voltage is lower than 9V+-5%. Restore: Raise the voltage to 12V and reset the fault. For more information refer to Bosch Option Bus, page 13. Supervise: Monitor the voltage by MPU.
Page 152 When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. 3 -Output Failure – Onboard Output 1-2 Fault 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 153 The panel can not send the report to the destination 1 after four attempts. Restore: Make sure that reports can be sent and reset the fault. For more information refer to System Setting, page 71. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 154 Slow flash FAULT indicator (refer to Keypad Indicators, page 8 for a detailed description). When the tamper condition is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 155 Restore the receiver and reset the tamper condition. For more information refer to RF Devices, page 83. Supervise: Report receiver tamper fault to configured destination when the fault is detected. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 156 Slow flash FAULT indicator (refer to Keypad Indicators, page 8 for a detailed description). When the fault is reset, send the restored report to the configured destinations. The FAULT indicator is turned off when there is no other system fault. 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 157: Maintenance
The LED of the firmware upgrade key flickers while the upgrade is sent to the AMAX panel. This takes about one minute. When upgrade is terminated, the LED blinks slowly. Remove upgrade key. Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 158: Technical Data
Aux 1 / 2 output Aux 1 / 2 output voltage +12V / GND Aux 1 / 2 nominal output voltage 13.8 (+3% / -5%) under AC line input in VDC 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 159 Option bus 2 maximum current in mA Battery Battery type 12 V / 7 Ah 12 V / 7Ah / 12 V / 18 Ah Bosch D 126 Bosch IPS-BAT12V-18AH Low battery condition in VDC below 11.0 Minimum battery condition in 10.8...
Page 160 Number of RF keyfobs DSRF = 24, Radion = 128 Zones Zone 1 Single or dual end-of-line 2 wire fire zone, single, or (EOL 2,2KΩ) dual end-of-line (EOL 2,2KΩ) NC, NO NC, NO 2015.05 | 06 | F.01U.309.277 Installation Manual Bosch Sicherheitssysteme GmbH...
Page 161 EN 60950-1:2006 + A11:2009 EN 50131-3 grade 2 Environmental class II France AFNOR NF a2P 1223400001 NF a2P 1223400002 Environmental class I Belgium INCERT (only for AMAX 3000 BE) Germany Home Bosch Sicherheitssysteme GmbH Installation Manual 2015.05 | 06 | F.01U.309.277...
Page 162 All manuals and user guides at all-guides.com...
Page 163 All manuals and user guides at all-guides.com...
Page 164 All manuals and user guides at all-guides.com Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2015...

This manual is also suitable for:

Amax panel 3000 Amax panel 3000 be Amax panel 4000

Bosch AMAX panel 2100 Installation Manual

Quick Links

Related Manuals for Bosch AMAX panel 2100

Summary of Contents for Bosch AMAX panel 2100

This manual is also suitable for:

Table of Contents
