Cable Management

A cable management unit attaches to the rear of the system rack. There are two types
of cable management units.
Some racks allow the routing of cables along both sides of the rack. The type A
■
cable plate (
of the rack.
Some racks allow routing of cables only along the right side of the rack. The type
■
B cable plate (
rack.
FIGURE 1-9
3
Figure Legend
1
2
3
) supports cable routing along both the left and right sides
FIGURE 1-9
FIGURE 1-10
Cable Management Unit (Type A) for Routing Cables to Both Sides of the
Rack
2
1
Type A cable plate
Support brackets
Cable plate locking screws
) is optimized for cable routing along the right side of the
3
2
Chapter 1 Overview 1-13
