3. Place the cable plate between the support brackets (
On each side of the cable plate, the forward tab rests on the bottom of the large
cutout in the support bracket. The rear tab rests in a small depression in the top of
the support bracket. This is the normal operating position for the cable plate.
FIGURE 2-10
1
Figure Legend
1
2
3
4. Tighten the green cable plate locking screws at each side of the cable plate.
5. Tighten the mounting screws on the support brackets.
2-12
External I/O Expansion Unit Installation and Service Manual for SPARC Enterprise T5xxx Servers • April 2011
Cable Plate and Support Bracket, Side View
2
3
Cable plate
Support bracket
Supporting tabs on the cable plate
).
FIGURE 2-10
