c. Press on the metal front panel of the carrier to push the carrier fully into the
carrier slot.
Caution – Do not press the plastic carrier handle during
handle, the PCI card and the sliding carrier plate might suddenly fall, breaking the
plastic locator bar (
FIGURE 3-17
d. Push the carrier handle into the closed position.
This action seats the PCI card in the card socket.
Caution – If the carrier handle does not close easily, the PCI card might not be
seating properly in the card socket in the I/O boat. Remove the carrier and inspect
the PCI card. If the bottom of the PCI card is not perfectly horizontal, loosen the card
locks and realign the card on the carrier. For troubleshooting information, see
Appendix E.
e. Lock the carrier handle into place with the carrier locking screw located on
the top of the handle.
7. Install PCI cards in the I/O boat.
See Step 5 and Step 6
8. Move the cable plate to the service position:
a. Loosen the cable plate locking screw(s) (item 3 in
b. Pull the cable plate toward you approximately 0.5 in./13 mm, then raise it
approximately 0.75 in./20 mm, until the bottom of the plate is above the tops
of the support brackets.
c. Push the cable plate forward to its service position (
cable plate rests on the support brackets.
The tabs on the sides of the cable plate should lie in the small notches on the
tops of the support brackets.
9. Remove the filler panel from the unused I/O boat slot by loosening the two
captive screws at the top of the filler panel.
A pivoting flap behind the filler panel drops down to prevent loss of cooling air.
10. Insert the I/O boat into the available slot.
The pivoting flap automatically swings up and out of the way.
11. Lock the I/O boat in place with the two captive screws at the top of the I/O boat.
) by hitting it against the lower edge of the I/O boat.
above for instructions to safely remove and insert carriers.
Chapter 4
Step c. If you press the
).
FIGURE 4-4
FIGURE 4-4
Servicing and Replacing Components
) so that the
4-15
