1.3.3.1

Tightening Sequence for Wide Cards

FIGURE 1-16
●
Rest the bottom edge of the PCI card on the type C card lock (number 1 in
FIGURE 1-16
then tighten the remaining card locks in the sequence shown.
1.3.3.2

Tightening Sequence for Narrow Cards

FIGURE 1-17
●
Tighten the upper left card lock (number 1 in
the card is perfectly horizontal. Then tighten the remaining card locks in the
sequence shown, as applicable.
Card Lock Sequence for Wide Cards
2 3
) to ensure that the bottom of the PCI card is perfectly horizontal,
Card Lock Sequence for Narrow Cards
1
4
1
2
3
FIGURE 1-17
4
), while ensuring that
Chapter 1 Overview 1-21
