2.4

Installing the Cable Management Unit

At the rear of the rack, install the cable management support brackets:
1. Use an antistatic strap for this procedure.
2. Place the support brackets just above the chassis mounting brackets (
and loosely attach the support brackets to the rack with two screws each.
Do not tighten the screws yet.
Note – The cable management unit includes one cable plate, either type A
(
FIGURE 2-8
Use the type A cable plate in racks that allow the routing of cables along both
■
sides of the rack.
Use the type B cable plate in racks that allow the routing of cables only along the
■
right side of the rack.
) or type B (
FIGURE 2-9
Chapter 2
).
Installing the External I/O Expansion Unit in a Rack
)
FIGURE 2-7
2-9
